EDC16C34 0281012528 1037386154 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 206 1.4 HDi (PSA 9664620780): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (5 ZIPs, 3.6 MB in total)
✔ EDC16C34 0281012528 1037386154 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Peugeot 206 1.4 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as 5 ZIPs with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. In addition, the download link is available right after payment.
5 independent reads of the same software, from 5 different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Peugeot 206 | — | — | 68 hp / 50 kW | — | confirmed for this software |
| Peugeot 206 | 1.4 HDi | 8HZ | 70 hp / 50 kW | 2006-2007 | confirmed for this software |
| Peugeot 307 | 2.0 HDi | — | — | — | reported, not confirmed |
Two 206 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281012528, PSA 9664620780 – and the software 1037386154 shown by your tool before ordering.
Same hardware 0281012528, different software 1037374477? That one is sold separately here.
Archive contents
Read #1 – 0281012528_9664620780_SW1037386154_N1.zip (719 KB)
| File | Memory | Size |
|---|---|---|
0281012528_9664620780_SW1037386154_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012528_9664620780_SW1037386154_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012528_9664620780_SW1037386154_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012528_9664620780_SW1037386154_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281012528_9664620780_SW1037386154_N2.zip (734 KB)
| File | Memory | Size |
|---|---|---|
0281012528_9664620780_SW1037386154_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012528_9664620780_SW1037386154_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012528_9664620780_SW1037386154_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012528_9664620780_SW1037386154_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281012528_9664620780_SW1037386154_N3.zip (735 KB)
| File | Memory | Size |
|---|---|---|
0281012528_9664620780_SW1037386154_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012528_9664620780_SW1037386154_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012528_9664620780_SW1037386154_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012528_9664620780_SW1037386154_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #4 – 0281012528_9664620780_SW1037386154_N4.zip (735 KB)
| File | Memory | Size |
|---|---|---|
0281012528_9664620780_SW1037386154_N4_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012528_9664620780_SW1037386154_N4_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012528_9664620780_SW1037386154_N4_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012528_9664620780_SW1037386154_N4_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #5 – 0281012528_9664620780_SW1037386154_N5.zip (734 KB)
| File | Memory | Size |
|---|---|---|
0281012528_9664620780_SW1037386154_N5_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012528_9664620780_SW1037386154_N5_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012528_9664620780_SW1037386154_N5_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012528_9664620780_SW1037386154_N5_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 13 bytes differ in the flash (5 areas: 0x007FC2–0x007FC6, 0x007FC8–0x007FCB, 0x03FA86, …); 279 bytes differ in the EEPROM (107 areas: 0x000001–0x000003, 0x000008, 0x00000E, …).
Read #3 compared with read #1: 15 bytes differ in the flash (3 areas: 0x007FC2–0x007FCB, 0x03FA86–0x03FA88, 0x03FAAE–0x03FAAF); 372 bytes differ in the EEPROM (139 areas: 0x000001–0x000003, 0x000008, 0x00000A–0x00000B, …).
Read #4 compared with read #1: 11 bytes differ in the flash (4 areas: 0x007FC4–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 475 bytes differ in the EEPROM (140 areas: 0x000001–0x000003, 0x00000A–0x00000B, 0x00000D–0x00000E, …).
Read #5 compared with read #1: 15 bytes differ in the flash (3 areas: 0x007FC2–0x007FCB, 0x03FA86–0x03FA88, 0x03FAAE–0x03FAAF); 298 bytes differ in the EEPROM (111 areas: 0x000001–0x000003, 0x000008, 0x00000A–0x00000B, …).
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281012528 1037386154 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012528 – printed 0 281 012 528 on the label |
| PSA part number | 9664620780 – printed 96 646 207 80 |
| Software (SW) | 1037386154 – also written SW1037386154 |
| Upgrade / SW upg. | none – your tool shows 1037386154 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 3.6 MB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
We read 5 EDC16C34 ECUs running software 1037386154 for this page. Hardware 0281012528 is known with 4 software versions in our catalogue; this page is 1037386154. Engine: Peugeot 206 1.4 HDi (70 hp, engine code 8HZ, 2006-2007).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 012 528 and the PSA number 96 646 207 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037386154 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037386154 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037386154 again |
Your tool should show 1037386154 as SW and either nothing or 1037386154 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281012528: SW 1037374477 (PSA 9659341880) – 206 1.4 HDi
- Other Peugeot 206 EDC16C34 files: 0281011861 · 1037370576 · 0281011784 · 1037371040 · 0281011560 · 1037371082 · 0281011783 · 1037372088 · 0281011783 · 1037372285
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012528 1037386154 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 206 1.4 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037386154.
My tool shows SW 1037386154 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 012 528 and 96 646 207 80 on the label; if the upgrade line is empty or repeats 1037386154, this is your file.
Will this file work on a Peugeot 307 2.0 HDi?
Only if the 307 label reads HW 0281012528 / PSA 9664620780 and the tool shows 1037386154. It is reported with this software but we did not read it from a 307 ourselves.
Same hardware 0281012528 but my tool shows SW 1037374477?
Then you need the other file for this hardware: SW 1037374477 with PSA 9659341880, sold on its own page. 0281012528 alone is not enough to choose.
Why are there 5 downloads for one software?
We read 5 ECUs running 1037386154. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281012528, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
