EDC16C34 0281012984 1037380085 1037386161 is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 206 1.6 HDi (PSA 9662939780): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 705 KB)
✔ EDC16C34 0281012984 1037380085 1037386161 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (705 KB) holding the updated software of a Bosch EDC16C34 read on the bench (Peugeot 206 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Peugeot 206 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
Do not rely on the model alone: check HW 0281012984 and PSA 9662939780 on the label, then 1037380085 and 1037386161 on the identification screen of your tool.
If your 206 shows HW 0281012984 but SW 1037380721 (PSA 9662213380), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012984_9662939780_SW1037380085_MJ1037386161_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012984_9662939780_SW1037380085_MJ1037386161_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012984_9662939780_SW1037380085_MJ1037386161_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012984_9662939780_SW1037380085_MJ1037386161_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
EDC16C34 0281012984 1037380085 1037386161 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012984 – printed 0 281 012 984 on the label |
| PSA part number | 9662939780 – printed 96 629 397 80 |
| Software (SW) | 1037380085 – also written SW1037380085 |
| Upgrade / SW upg. | 1037386161 – also written MJ1037386161; your tool shows SW 1037380085 and SW upg. 1037386161 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 705 KB, instant download after payment |
Notes on this file
Hardware 0281012984 is known with 2 software versions in our catalogue; this page is 1037380085 updated to 1037386161. Engine: Peugeot 206 1.6 HDi (110 hp).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 012 984 and the PSA number 96 629 397 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037380085 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037380085 |
| SW upg. (SW màj., soft up, UpgSW) | 1037386161 |
Look for the pair 1037380085 / 1037386161 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1037386161 alone, points to this file; 1037380085 twice points to the non-updated read.
Other files you may need
- Same hardware 0281012984: SW 1037380721 (PSA 9662213380) – 407 1.6 HDi
- Other Peugeot 206 EDC16C34 files: 0281011861 · 1037370576 · 0281011784 · 1037371040 · 0281011560 · 1037371082 · 0281011783 · 1037372088 · 0281011783 · 1037372285
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012984 1037380085 1037386161 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 206 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037380085.
My tool shows SW 1037380085 and SW upg. 1037386161 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037386161, and 1037380085 is the base number the ECU still reports.
My tool shows only “SW upg. 1037386161” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281012984 and 9662939780 on the label and you are good.
Same hardware 0281012984 but my tool shows SW 1037380721?
Then you need the other file for this hardware: SW 1037380721 with PSA 9662213380, sold on its own page. 0281012984 alone is not enough to choose.
