EDC16C34 0281011560 1037371082 ORI: the unmodified full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 206 1.6 HDi (PSA 9656162180) – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) read on the bench.
What you get (ZIP, 662 KB)
✔ EDC16C34 0281011560 1037371082 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (662 KB) holding the software of a Bosch EDC16C34 read on the bench (Peugeot 206 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 206 | 1.6 HDi | 9HZ | 109 hp / 80 kW | confirmed for this software |
| Peugeot 206 | — | DV6TED4 | — | confirmed for this software |
| Citroën C3 | 1.6 HDi | 9HZ | — | reported, not confirmed |
| Peugeot 1007 | 1.6 HDi | 9HZ | — | reported, not confirmed |
Hardware 0281011560 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281011560 and PSA 9656162180 on the label, then the software number in your tool.
With HW 0281011560 but PSA 9659823880 / SW 1037375531, take that file.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011560_9656162180_SW1037371082_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011560_9656162180_SW1037371082_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011560_9656162180_SW1037371082_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011560_9656162180_SW1037371082_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011560 1037371082 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011560 – printed 0 281 011 560 on the label |
| PSA part number | 9656162180 – printed 96 561 621 80 |
| Software (SW) | 1037371082 – also written SW1037371082 |
| Upgrade / SW upg. | none – your tool shows 1037371082 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 662 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC16C34 (fichier d’origine in French, file ori in Italian).
Notes on this file
Hardware 0281011560 is known with 2 software versions in our catalogue; this page is 1037371082. Engine: Peugeot 206 1.6 HDi (109 hp, engine code 9HZ).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 011 560 and 96 561 621 80. The 1039S… sticker is not a software number – 1037371082 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037371082 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037371082 again |
Your tool should show 1037371082 as SW and either nothing or 1037371082 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281011560: SW 1037375531 (PSA 9659823880) – 206 1.6 HDi
- Other Peugeot 206 EDC16C34 files: 0281011861 · 1037370576 · 0281011784 · 1037371040 · 0281011783 · 1037372088 · 0281011783 · 1037372285 · 0281012525 · 1037374475
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011560 1037371082 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 206 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037371082.
My tool shows SW 1037371082 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 560 and 96 561 621 80 on the label; if the upgrade line is empty or repeats 1037371082, this is your file.
Will this file work on a Citroën C3 1.6 HDi?
Only if the C3 label reads HW 0281011560 / PSA 9656162180 and the tool shows 1037371082. It is reported with this software but we did not read it from a C3 ourselves.
Same hardware 0281011560 but my tool shows SW 1037375531?
Then you need the other file for this hardware: SW 1037375531 with PSA 9659823880, sold on its own page. 0281011560 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281011560, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
