EDC16C34 0281011861 1037370576 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Citroën C2 1.4 HDi (PSA 9657061180): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (4 ZIPs, 2.5 MB in total)
✔ EDC16C34 0281011861 1037370576 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC16C34, read on the bench (Citroën C2 1.4 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. In addition, the download link is available right after payment.
Four independent reads of the same software, from four different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën C2 | 1.4 HDi | 8HX | 68 hp / 50 kW | confirmed for this software |
| Citroën C3 | 1.4 HDi | — | 68 hp / 50 kW | confirmed for this software |
| Peugeot 206 | 1.4 HDi | — | 68 hp / 50 kW | confirmed for this software |
Two C2 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011861, PSA 9657061180 – and the software 1037370576 shown by your tool before ordering.
Archive contents
Read #1 – 0281011861_9657061180_SW1037370576_N1.zip (640 KB)
| File | Memory | Size |
|---|---|---|
0281011861_9657061180_SW1037370576_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011861_9657061180_SW1037370576_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011861_9657061180_SW1037370576_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011861_9657061180_SW1037370576_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011861_9657061180_SW1037370576_N2.zip (655 KB)
| File | Memory | Size |
|---|---|---|
0281011861_9657061180_SW1037370576_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011861_9657061180_SW1037370576_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011861_9657061180_SW1037370576_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011861_9657061180_SW1037370576_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281011861_9657061180_SW1037370576_N3.zip (655 KB)
| File | Memory | Size |
|---|---|---|
0281011861_9657061180_SW1037370576_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011861_9657061180_SW1037370576_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011861_9657061180_SW1037370576_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011861_9657061180_SW1037370576_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #4 – 0281011861_9657061180_SW1037370576_N4.zip (655 KB)
| File | Memory | Size |
|---|---|---|
0281011861_9657061180_SW1037370576_N4_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011861_9657061180_SW1037370576_N4_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011861_9657061180_SW1037370576_N4_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011861_9657061180_SW1037370576_N4_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 12 bytes differ in the flash (4 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 375 bytes differ in the EEPROM (92 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
Read #3 compared with read #1: 10 bytes differ in the flash (4 areas: 0x007FC3–0x007FC6, 0x007FC9–0x007FCB, 0x03FA86, …); 292 bytes differ in the EEPROM (92 areas: 0x000001–0x000003, 0x00000D–0x00000E, 0x000018–0x000019, …).
Read #4 compared with read #1: 11 bytes differ in the flash (4 areas: 0x007FC4–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 297 bytes differ in the EEPROM (78 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011861 1037370576 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011861 – printed 0 281 011 861 on the label |
| PSA part number | 9657061180 – printed 96 570 611 80 |
| Software (SW) | 1037370576 – also written SW1037370576 |
| Upgrade / SW upg. | none – your tool shows 1037370576 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 2.5 MB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC16C34 (fichier d’origine in French, file ori in Italian).
Notes on this file
We read four EDC16C34 ECUs running software 1037370576 for this page. Engine: Citroën C2 1.4 HDi (68 hp, engine code 8HX).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 011 861 and the PSA number 96 570 611 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037370576 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037370576 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037370576 again |
Expected ID screen: SW 1037370576, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Other Citroën C2 EDC16C34 files: 0281011785 · 1037371531 · 0281011785 · 1037372284
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011861 1037370576 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C2 1.4 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037370576.
My tool shows SW 1037370576 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 861 and 96 570 611 80 on the label; if the upgrade line is empty or repeats 1037370576, this is your file.
Does it fit the Citroën C3 1.4 HDi?
Yes – the C3 is confirmed for this software. Check 0 281 011 861 and 96 570 611 80 on the label and software 1037370576 in your tool before ordering.
Does it fit the Peugeot 206 1.4 HDi?
Yes – the 206 is confirmed for this software. Check 0 281 011 861 and 96 570 611 80 on the label and software 1037370576 in your tool before ordering.
Will this file work on a Mazda 2?
Only if the 2 label reads HW 0281011861 / PSA 9657061180 and the tool shows 1037370576. It is reported with this software but we did not read it from a 2 ourselves.
Why are there 4 downloads for one software?
We read 4 ECUs running 1037370576. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor C2?
Yes, as read. This is the original state of ECU 0281011861, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
