EDC16C34 0281011783 1037372285 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 206 1.4 HDi (PSA 9658556780): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (4 ZIPs, 2.4 MB in total)
✔ EDC16C34 0281011783 1037372285 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive holding the software of a Bosch EDC16C34 read on the bench (Peugeot 206 1.4 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Also, the download opens as soon as the payment is confirmed.
Four independent reads of the same software, from four different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 206 | 1.4 HDi | 8HZ | 68 hp / 50 kW | confirmed for this software |
| Peugeot 206 | 2.0 HDi | — | — | confirmed for this software |
Hardware 0281011783 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281011783 and PSA 9658556780 on the label, then the software number in your tool.
With HW 0281011783 but PSA 9656709780 / SW 1037372088, take that file.
Archive contents
Read #1 – 0281011783_9658556780_SW1037372285_N1.zip (615 KB)
| File | Memory | Size |
|---|---|---|
0281011783_9658556780_SW1037372285_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011783_9658556780_SW1037372285_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011783_9658556780_SW1037372285_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011783_9658556780_SW1037372285_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011783_9658556780_SW1037372285_N2.zip (630 KB)
| File | Memory | Size |
|---|---|---|
0281011783_9658556780_SW1037372285_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011783_9658556780_SW1037372285_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011783_9658556780_SW1037372285_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011783_9658556780_SW1037372285_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281011783_9658556780_SW1037372285_N3.zip (631 KB)
| File | Memory | Size |
|---|---|---|
0281011783_9658556780_SW1037372285_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011783_9658556780_SW1037372285_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011783_9658556780_SW1037372285_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011783_9658556780_SW1037372285_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #4 – 0281011783_9658556780_SW1037372285_N4.zip (630 KB)
| File | Memory | Size |
|---|---|---|
0281011783_9658556780_SW1037372285_N4_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011783_9658556780_SW1037372285_N4_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011783_9658556780_SW1037372285_N4_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011783_9658556780_SW1037372285_N4_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 9 bytes differ in the flash (4 areas: 0x007FC4–0x007FC6, 0x007FC9–0x007FCB, 0x03FA86, …); 251 bytes differ in the EEPROM (61 areas: 0x000002–0x000003, 0x00000E, 0x000019, …).
Read #3 compared with read #1: 11 bytes differ in the flash (4 areas: 0x007FC4–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 419 bytes differ in the EEPROM (93 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
Read #4 compared with read #1: 12 bytes differ in the flash (4 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 268 bytes differ in the EEPROM (64 areas: 0x000001–0x000003, 0x00000B, 0x00000E, …).
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011783 1037372285 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011783 – printed 0 281 011 783 on the label |
| PSA part number | 9658556780 – printed 96 585 567 80 |
| Software (SW) | 1037372285 – also written SW1037372285 |
| Upgrade / SW upg. | none – your tool shows 1037372285 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 2.4 MB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
We read four EDC16C34 ECUs running software 1037372285 for this page. Hardware 0281011783 is known with 2 software versions in our catalogue; this page is 1037372285. Engine: Peugeot 206 1.4 HDi (68 hp, engine code 8HZ).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 011 783 and 96 585 567 80. The 1039S… sticker is not a software number – 1037372285 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037372285 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037372285 again |
Expected ID screen: SW 1037372285, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281011783: SW 1037372088 (PSA 9656709780) – 206 1.4 HDi
- Other Peugeot 206 EDC16C34 files: 0281011861 · 1037370576 · 0281011784 · 1037371040 · 0281011560 · 1037371082 · 0281012525 · 1037374475 · 0281012528 · 1037374477
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011783 1037372285 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 206 1.4 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037372285.
My tool shows SW 1037372285 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 783 and 96 585 567 80 on the label; if the upgrade line is empty or repeats 1037372285, this is your file.
Same hardware 0281011783 but my tool shows SW 1037372088?
Then you need the other file for this hardware: SW 1037372088 with PSA 9656709780, sold on its own page. 0281011783 alone is not enough to choose.
Why are there 4 downloads for one software?
We read 4 ECUs running 1037372285. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281011783, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
