EDC15C2 0281010250 1037359222 ORI: the unmodified full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 206 2.0 HDi (PSA 9637089980) – external flash 512 KB + EEPROM 95080 (1 KB) read on the bench.
What you get (ZIP, 361 KB)
✔ EDC15C2 0281010250 1037359222 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC15C2 used in the Peugeot 206 2.0 HDi: external flash 512 KB + EEPROM 95080 (1 KB) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 206 | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
Two 206 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010250, PSA 9637089980 – and the software 1037359222 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010250_9637089980_SW1037359222_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010250_9637089980_SW1037359222_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010250 1037359222 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010250 – printed 0 281 010 250 on the label |
| PSA part number | 9637089980 – printed 96 370 899 80 |
| Software (SW) | 1037359222 – also written SW1037359222 |
| Upgrade / SW upg. | none – your tool shows 1037359222 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 361 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
Hardware 0281010250 is known with 2 software versions in our catalogue; this page is 1037359222. Engine: Peugeot 206 2.0 HDi (90 hp, engine code RHY).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C2 you will read 0 281 010 250 (hardware) and 96 370 899 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037359222 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037359222 again |
Your tool should show 1037359222 as SW and either nothing or 1037359222 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010250 1037359222 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 206 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037359222.
My tool shows SW 1037359222 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 250 and 96 370 899 80 on the label; if the upgrade line is empty or repeats 1037359222, this is your file.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281010250, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
