EDC15C2 0281010767 1037353536 ORI – original flash read from a Bosch EDC15C2 fitted to the Peugeot 206 2.0 HDi (PSA 9643524980): external flash 512 KB, bench read, nothing modified.
What you get (ZIP, 397 KB)
✔ EDC15C2 0281010767 1037353536 ORI original read – external flash 512 KB
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (397 KB) holding the software of a Bosch EDC15C2 read on the bench (Peugeot 206 2.0 HDi application): external flash 512 KB from the same unit, with an INFOS.html datasheet.
In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 206 | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
| Peugeot 607 | 2.2 HDi | — | — | reported, not confirmed |
Do not rely on the model alone: check HW 0281010767 and PSA 9643524980 on the label, then 1037353536 on the identification screen of your tool.
With HW 0281010767 but PSA 9643524980 / SW 1037353735, take that file.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010767_9643524980_SW1037353536_FLASH.bin | External flash | 524 288 bytes (512 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
EDC15C2 0281010767 1037353536 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010767 – printed 0 281 010 767 on the label |
| PSA part number | 9643524980 – printed 96 435 249 80 |
| Software (SW) | 1037353536 – also written SW1037353536 |
| Upgrade / SW upg. | none – your tool shows 1037353536 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 397 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Hardware 0281010767 is known with 2 software versions in our catalogue; this page is 1037353536. Engine: Peugeot 206 2.0 HDi (90 hp, engine code RHY).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 010 767 and 96 435 249 80. The 1039S… sticker is not a software number – 1037353536 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037353536 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037353536 again |
Your tool should show 1037353536 as SW and either nothing or 1037353536 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281010767: SW 1037353735 (PSA 9643524980) – 206 2.0 HDi
- Other Peugeot 206 EDC15C2 files: 0281010500 · 1037353319 · 0281010594 · 1037353648 · 0281001866 · 1037359123 · 0281001974 · 1037359124 · 0281010250 · 1037359222
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010767 1037353536 ORI a full BDM backup or only the flash?
This set holds the external flash only (no EEPROM): the original, unmodified flash read of 1037353536.
My tool shows SW 1037353536 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 767 and 96 435 249 80 on the label; if the upgrade line is empty or repeats 1037353536, this is your file.
Will this file work on a Citroën C5?
Only if the C5 label reads HW 0281010767 / PSA 9643524980 and the tool shows 1037353536. It is reported with this software but we did not read it from a C5 ourselves.
Same hardware 0281010767 but my tool shows SW 1037353735?
Then you need the other file for this hardware: SW 1037353735 with PSA 9643524980, sold on its own page. 0281010767 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281010767, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
