EDC15C2 0281010500 1037353319 ORI – original full BDM backup from a Bosch EDC15C2 fitted to the Peugeot 206 2.0 HDi (PSA 9641606980): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 397 KB)
✔ EDC15C2 0281010500 1037353319 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (397 KB) holding the software of a Bosch EDC15C2 read on the bench (Peugeot 206 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB) from the same unit, with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 206 | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
Two 206 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010500, PSA 9641606980 – and the software 1037353319 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010500_9641606980_SW1037353319_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010500_9641606980_SW1037353319_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010500 1037353319 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010500 – printed 0 281 010 500 on the label |
| PSA part number | 9641606980 – printed 96 416 069 80 |
| Software (SW) | 1037353319 – also written SW1037353319 |
| Upgrade / SW upg. | none – your tool shows 1037353319 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 397 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Engine: Peugeot 206 2.0 HDi (90 hp, engine code RHY).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C2. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C2 you will read 0 281 010 500 (hardware) and 96 416 069 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037353319 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037353319 again |
Your tool should show 1037353319 as SW and either nothing or 1037353319 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010500 1037353319 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 206 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037353319.
My tool shows SW 1037353319 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 500 and 96 416 069 80 on the label; if the upgrade line is empty or repeats 1037353319, this is your file.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281010500, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
