EDC16C34 0281012983 1037380085 ORI – original full BDM backup from a Bosch EDC16C34 fitted to the Peugeot 206 1.6 HDi (PSA 9662939780): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (ZIP, 699 KB)
✔ EDC16C34 0281012983 1037380085 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Peugeot 206 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Peugeot 206 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
Do not rely on the model alone: check HW 0281012983 and PSA 9662939780 on the label, then 1037380085 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012983_9662939780_SW1037380085_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012983_9662939780_SW1037380085_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012983_9662939780_SW1037380085_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012983_9662939780_SW1037380085_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281012983 1037380085 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012983 – printed 0 281 012 983 on the label |
| PSA part number | 9662939780 – printed 96 629 397 80 |
| Software (SW) | 1037380085 – also written SW1037380085 |
| Upgrade / SW upg. | none – your tool shows 1037380085 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 699 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC16C34 (fichier d’origine in French, file ori in Italian).
Notes on this file
Engine: Peugeot 206 1.6 HDi (110 hp).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 012 983 (hardware) and 96 629 397 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037380085 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037380085 again |
Expected ID screen: SW 1037380085, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Other Peugeot 206 EDC16C34 files: 0281011861 · 1037370576 · 0281011784 · 1037371040 · 0281011560 · 1037371082 · 0281011783 · 1037372088 · 0281011783 · 1037372285
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012983 1037380085 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 206 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037380085.
My tool shows SW 1037380085 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 012 983 and 96 629 397 80 on the label; if the upgrade line is empty or repeats 1037380085, this is your file.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281012983, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
