EDC16C34 0281012523 1037386170 1037389509 is the original full BDM backup of a Bosch EDC16C34 fitted to the Citroën C3 1.4 HDi (PSA 9664843480): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (5 ZIPs, 3.7 MB in total)
✔ EDC16C34 0281012523 1037386170 1037389509 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën C3 1.4 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as 5 ZIPs with an INFOS.html datasheet.
In addition, the download link is available right after payment.
5 independent reads of the same software, from 5 different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Citroën C3 | 1.4 HDi | 68 hp / 50 kW | confirmed for this software |
| Peugeot 207 | 1.4 HDi | 68 hp / 50 kW | confirmed for this software |
| Peugeot 206 | 1.4 HDi | — | reported, not confirmed |
Hardware 0281012523 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281012523 and PSA 9664843480 on the label, then the software numbers in your tool.
With HW 0281012523 but PSA 9662212480 / SW 1037379395, take that file.
Archive contents
Read #1 – 0281012523_9664843480_SW1037386170_MJ1037389509_N1.zip (736 KB)
| File | Memory | Size |
|---|---|---|
0281012523_9664843480_SW1037386170_MJ1037389509_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281012523_9664843480_SW1037386170_MJ1037389509_N2.zip (752 KB)
| File | Memory | Size |
|---|---|---|
0281012523_9664843480_SW1037386170_MJ1037389509_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281012523_9664843480_SW1037386170_MJ1037389509_N3.zip (752 KB)
| File | Memory | Size |
|---|---|---|
0281012523_9664843480_SW1037386170_MJ1037389509_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #4 – 0281012523_9664843480_SW1037386170_MJ1037389509_N4.zip (752 KB)
| File | Memory | Size |
|---|---|---|
0281012523_9664843480_SW1037386170_MJ1037389509_N4_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N4_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N4_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N4_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #5 – 0281012523_9664843480_SW1037386170_MJ1037389509_N5.zip (752 KB)
| File | Memory | Size |
|---|---|---|
0281012523_9664843480_SW1037386170_MJ1037389509_N5_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N5_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N5_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012523_9664843480_SW1037386170_MJ1037389509_N5_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 12 bytes differ in the flash (6 areas: 0x007FC4–0x007FC6, 0x007FC9–0x007FCB, 0x03FA86, …); 594 bytes differ in the EEPROM (152 areas: 0x000001–0x000003, 0x00000E, 0x000019, …).
Read #3 compared with read #1: 12 bytes differ in the flash (6 areas: 0x007FC4–0x007FC6, 0x007FC9–0x007FCB, 0x03FA86, …); 588 bytes differ in the EEPROM (147 areas: 0x000001–0x000003, 0x00000D–0x00000E, 0x000018–0x000019, …).
Read #4 compared with read #1: 16 bytes differ in the flash (6 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 581 bytes differ in the EEPROM (159 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
Read #5 compared with read #1: 15 bytes differ in the flash (6 areas: 0x007FC4–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 602 bytes differ in the EEPROM (161 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
EDC16C34 0281012523 1037386170 1037389509 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012523 – printed 0 281 012 523 on the label |
| PSA part number | 9664843480 – printed 96 648 434 80 |
| Software (SW) | 1037386170 – also written SW1037386170 |
| Upgrade / SW upg. | 1037389509 – also written MJ1037389509; your tool shows SW 1037386170 and SW upg. 1037389509 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 3.7 MB, instant download after payment |
Notes on this file
We read 5 EDC16C34 ECUs running software 1037386170 for this page. Hardware 0281012523 is known with 2 software versions in our catalogue; this page is 1037386170 updated to 1037389509. Engine: Citroën C3 1.4 HDi (68 hp).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 012 523 and 96 648 434 80. The 1039S… sticker is not a software number – 1037386170 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037386170 |
| SW upg. (SW màj., soft up, UpgSW) | 1037389509 |
Look for the pair 1037386170 / 1037389509 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1037389509 alone, points to this file; 1037386170 twice points to the non-updated read.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037389509 | SW 1037386170 / SW upg. 1037389509 | C3 1.4 HDi | this file |
| upgrade 1037389541 | SW 1037386170 / SW upg. 1037389541 | C3 1.4 HDi | open |
| upgrade 1037393450 | SW 1037386170 / SW upg. 1037393450 | C3 1.4 HDi | open |
| upgrade 1037395390 | SW 1037386170 / SW upg. 1037395390 | C3 1.4 HDi | open |
| upgrade 1037398224 | SW 1037386170 / SW upg. 1037398224 | C3 1.4 HDi | open |
| upgrade 1039398214 | SW 1037386170 / SW upg. 1039398214 | C3 1.4 HDi | open |
- Same hardware 0281012523: SW 1037379395 (PSA 9662212480) – 207 1.6 HDi
- Other Citroën C3 EDC16C34 files: 0281011861 · 1037370576 · 0281011785 · 1037371531 · 0281011785 · 1037372284 · 0281012524 · 1037375520 · 0281011804 · 1037375953
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012523 1037386170 1037389509 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C3 1.4 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037386170.
My tool shows SW 1037386170 and SW upg. 1037389509 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037389509, and 1037386170 is the base number the ECU still reports.
My tool shows only “SW upg. 1037389509” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281012523 and 9664843480 on the label and you are good.
Does it fit the Peugeot 207 1.4 HDi?
Yes – the 207 is confirmed for this software. Check 0 281 012 523 and 96 648 434 80 on the label and software 1037386170 in your tool before ordering.
Will this file work on a Peugeot 206 1.4 HDi?
Only if the 206 label reads HW 0281012523 / PSA 9664843480 and the tool shows 1037386170 / 1037389509. It is reported with this software but we did not read it from a 206 ourselves.
