EDC16C34 0281012523 1037379395 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 207 1.6 HDi (PSA 9662212480): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 653 KB)
✔ EDC16C34 0281012523 1037379395 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Peugeot 207 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 207 | 1.6 HDi | 9HX | 90 hp / 66 kW | confirmed for this software |
| Peugeot 207 | 1.6 DIESEL | — | — | reported, not confirmed |
Do not rely on the model alone: check HW 0281012523 and PSA 9662212480 on the label, then 1037379395 on the identification screen of your tool.
If your 207 shows HW 0281012523 but SW 1037386170 (PSA 9664843480), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012523_9662212480_SW1037379395_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012523_9662212480_SW1037379395_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012523_9662212480_SW1037379395_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012523_9662212480_SW1037379395_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281012523 1037379395 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012523 – printed 0 281 012 523 on the label |
| PSA part number | 9662212480 – printed 96 622 124 80 |
| Software (SW) | 1037379395 – also written SW1037379395 |
| Upgrade / SW upg. | none – your tool shows 1037379395 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 653 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC16C34 (fichier d’origine in French, file ori in Italian).
Notes on this file
Hardware 0281012523 is known with 2 software versions in our catalogue; this page is 1037379395. Engine: Peugeot 207 1.6 HDi (90 hp, engine code 9HX).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 012 523 and the PSA number 96 622 124 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037379395 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037379395 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037379395 again |
Expected ID screen: SW 1037379395, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281012523: SW 1037386170 (PSA 9664843480) – C3 1.4 HDi · SW 1037386170 (PSA 9664843480) – C3 1.4 HDi · SW 1037386170 (PSA 9664843480) – C3 1.4 HDi · SW 1037386170 (PSA 9664843480) – C3 1.4 HDi · SW 1037386170 (PSA 9664843480) – C3 1.4 HDi
- Other Peugeot 207 EDC16C34 files: 0281012465 · 1037375963 · 0281012529 · 1037379216 upg. 1037380738 · 0281012985 · 1037379394 upg. 1037386114 · 0281012985 · 1037379394 upg. 1037386115 · 0281012985 · 1037379394 upg. 1039398213
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012523 1037379395 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 207 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037379395.
My tool shows SW 1037379395 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 012 523 and 96 622 124 80 on the label; if the upgrade line is empty or repeats 1037379395, this is your file.
Will this file work on a Peugeot 207 1.6 DIESEL?
Only if the 207 label reads HW 0281012523 / PSA 9662212480 and the tool shows 1037379395. It is reported with this software but we did not read it from a 207 ourselves.
Same hardware 0281012523 but my tool shows SW 1037386170?
Then you need the other file for this hardware: SW 1037386170 with PSA 9664843480, sold on its own page. 0281012523 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 207?
Yes, as read. This is the original state of ECU 0281012523, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
