EDC16C34 0281012524 1037375520 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Citroën C3 1.4 HDi (PSA 9661728480): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 697 KB)
✔ EDC16C34 0281012524 1037375520 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (697 KB) with the complete memory of a Bosch EDC16C34, read on the bench (Citroën C3 1.4 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Citroën C3 | 1.4 HDi | confirmed for this software |
Do not rely on the model alone: check HW 0281012524 and PSA 9661728480 on the label, then 1037375520 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012524_9661728480_SW1037375520_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012524_9661728480_SW1037375520_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012524_9661728480_SW1037375520_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012524_9661728480_SW1037375520_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281012524 1037375520 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012524 – printed 0 281 012 524 on the label |
| PSA part number | 9661728480 – printed 96 617 284 80 |
| Software (SW) | 1037375520 – also written SW1037375520 |
| Upgrade / SW upg. | none – your tool shows 1037375520 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 697 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
This page covers one exact software: EDC16C34 0281012524 with SW 1037375520. Another number on your tool means another file – use the search or ask us.
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 012 524 and the PSA number 96 617 284 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037375520 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037375520 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037375520 again |
Expected ID screen: SW 1037375520, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Other Citroën C3 EDC16C34 files: 0281011861 · 1037370576 · 0281011785 · 1037371531 · 0281011785 · 1037372284 · 0281011804 · 1037375953 · 0281012529 · 1037379216 upg. 1037380738
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012524 1037375520 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C3 1.4 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037375520.
My tool shows SW 1037375520 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 012 524 and 96 617 284 80 on the label; if the upgrade line is empty or repeats 1037375520, this is your file.
Does the EEPROM contain the immobiliser of the donor C3?
Yes, as read. This is the original state of ECU 0281012524, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
