EDC16C34 0281011785 1037372284 ORI – original full BDM backup from a Bosch EDC16C34 fitted to the Citroën C2 1.4 HDi (PSA 9658556880): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (5 ZIPs, 3.2 MB in total)
✔ EDC16C34 0281011785 1037372284 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC16C34, read on the bench (Citroën C2 1.4 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. Also, the download opens as soon as the payment is confirmed.
5 independent reads of the same software, from 5 different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Citroën C2 | 1.4 HDi | 68 hp / 50 kW | confirmed for this software |
| Citroën C2 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
| Citroën C3 | 1.4 HDi | 68 hp / 50 kW | confirmed for this software |
Do not rely on the model alone: check HW 0281011785 and PSA 9658556880 on the label, then 1037372284 on the identification screen of your tool.
Same hardware 0281011785, different software 1037371531? That one is sold separately here.
Archive contents
Read #1 – 0281011785_9658556880_SW1037372284_N1.zip (648 KB)
| File | Memory | Size |
|---|---|---|
0281011785_9658556880_SW1037372284_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011785_9658556880_SW1037372284_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011785_9658556880_SW1037372284_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011785_9658556880_SW1037372284_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011785_9658556880_SW1037372284_N2.zip (663 KB)
| File | Memory | Size |
|---|---|---|
0281011785_9658556880_SW1037372284_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011785_9658556880_SW1037372284_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011785_9658556880_SW1037372284_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011785_9658556880_SW1037372284_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281011785_9658556880_SW1037372284_N3.zip (663 KB)
| File | Memory | Size |
|---|---|---|
0281011785_9658556880_SW1037372284_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011785_9658556880_SW1037372284_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011785_9658556880_SW1037372284_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011785_9658556880_SW1037372284_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #4 – 0281011785_9658556880_SW1037372284_N4.zip (663 KB)
| File | Memory | Size |
|---|---|---|
0281011785_9658556880_SW1037372284_N4_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011785_9658556880_SW1037372284_N4_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011785_9658556880_SW1037372284_N4_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011785_9658556880_SW1037372284_N4_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #5 – 0281011785_9658556880_SW1037372284_N5.zip (663 KB)
| File | Memory | Size |
|---|---|---|
0281011785_9658556880_SW1037372284_N5_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011785_9658556880_SW1037372284_N5_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011785_9658556880_SW1037372284_N5_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011785_9658556880_SW1037372284_N5_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 12 bytes differ in the flash (4 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 375 bytes differ in the EEPROM (84 areas: 0x000001–0x000003, 0x00000B, 0x00000D, …).
Read #3 compared with read #1: 12 bytes differ in the flash (4 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 381 bytes differ in the EEPROM (93 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
Read #4 compared with read #1: 12 bytes differ in the flash (4 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 383 bytes differ in the EEPROM (86 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
Read #5 compared with read #1: 12 bytes differ in the flash (4 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 428 bytes differ in the EEPROM (119 areas: 0x000001–0x000003, 0x00000B, 0x00000E, …).
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011785 1037372284 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011785 – printed 0 281 011 785 on the label |
| PSA part number | 9658556880 – printed 96 585 568 80 |
| Software (SW) | 1037372284 – also written SW1037372284 |
| Upgrade / SW upg. | none – your tool shows 1037372284 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 3.2 MB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
We read 5 EDC16C34 ECUs running software 1037372284 for this page. Hardware 0281011785 is known with 2 software versions in our catalogue; this page is 1037372284. Engine: Citroën C2 1.4 HDi (68 hp).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 011 785 (hardware) and 96 585 568 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037372284 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037372284 again |
Expected ID screen: SW 1037372284, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281011785: SW 1037371531 (PSA 9656709880) – C2 1.4 HDi
- Other Citroën C2 EDC16C34 files: 0281011861 · 1037370576
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011785 1037372284 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C2 1.4 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037372284.
My tool shows SW 1037372284 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 785 and 96 585 568 80 on the label; if the upgrade line is empty or repeats 1037372284, this is your file.
Will this file work on a Citroën Nemo?
Only if the Nemo label reads HW 0281011785 / PSA 9658556880 and the tool shows 1037372284. It is reported with this software but we did not read it from a Nemo ourselves.
Same hardware 0281011785 but my tool shows SW 1037371531?
Then you need the other file for this hardware: SW 1037371531 with PSA 9656709880, sold on its own page. 0281011785 alone is not enough to choose.
Why are there 5 downloads for one software?
We read 5 ECUs running 1037372284. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor C2?
Yes, as read. This is the original state of ECU 0281011785, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
