EDC16C34 0281011628 1037375951 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 206 1.6 HDi (PSA 9659823980): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 658 KB)
✔ EDC16C34 0281011628 1037375951 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (658 KB) holding the software of a Bosch EDC16C34 read on the bench (Peugeot 206 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 206 | 1.6 HDi | 9HZ | 110 hp / 80 kW | confirmed for this software |
| Peugeot 206 | — | 9HZ | — | confirmed for this software |
Hardware 0281011628 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281011628 and PSA 9659823980 on the label, then the software number in your tool.
With HW 0281011628 but PSA 9655924180 / SW 1037374955, take that file.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011628_9659823980_SW1037375951_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011628_9659823980_SW1037375951_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011628_9659823980_SW1037375951_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011628_9659823980_SW1037375951_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011628 1037375951 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011628 – printed 0 281 011 628 on the label |
| PSA part number | 9659823980 – printed 96 598 239 80 |
| Software (SW) | 1037375951 – also written SW1037375951 |
| Upgrade / SW upg. | none – your tool shows 1037375951 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 658 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Hardware 0281011628 is known with 2 software versions in our catalogue; this page is 1037375951. Engine: Peugeot 206 1.6 HDi (110 hp, engine code 9HZ).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 011 628 (hardware) and 96 598 239 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037375951 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037375951 again |
Expected ID screen: SW 1037375951, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281011628: SW 1037374955 (PSA 9655924180) – 206 1.6 HDi
- Other Peugeot 206 EDC16C34 files: 0281011861 · 1037370576 · 0281011784 · 1037371040 · 0281011560 · 1037371082 · 0281011783 · 1037372088 · 0281011783 · 1037372285
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011628 1037375951 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 206 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037375951.
My tool shows SW 1037375951 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 628 and 96 598 239 80 on the label; if the upgrade line is empty or repeats 1037375951, this is your file.
Same hardware 0281011628 but my tool shows SW 1037374955?
Then you need the other file for this hardware: SW 1037374955 with PSA 9655924180, sold on its own page. 0281011628 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281011628, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
