EDC16C34 0281012985 1037379394 1037386115 – original full BDM backup from a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9661204380): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (3 ZIPs, 2.1 MB in total)
✔ EDC16C34 0281012985 1037379394 1037386115 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC16C34, read on the bench (Citroën C4 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
Also, the download opens as soon as the payment is confirmed.
Three independent reads of the same software, from three different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | 9HY | 110 hp / 80 kW | confirmed for this software |
| Peugeot 207 | 1.6 HDi | 9HY | 110 hp / 80 kW | confirmed for this software |
| Peugeot 307 | 1.6 HDi | 9HY | 110 hp / 80 kW | confirmed for this software |
| Peugeot 308 | 1.6 HDi | 9HT | 110 hp / 80 kW | reported, not confirmed |
Hardware 0281012985 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281012985 and PSA 9661204380 on the label, then the software numbers in your tool.
If your C4 shows HW 0281012985 but SW 1037386166 (PSA 9664843780), you need this other file instead.
Archive contents
Read #1 – 0281012985_9661204380_SW1037379394_MJ1037386115_N1.zip (718 KB)
| File | Memory | Size |
|---|---|---|
0281012985_9661204380_SW1037379394_MJ1037386115_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281012985_9661204380_SW1037379394_MJ1037386115_N2.zip (733 KB)
| File | Memory | Size |
|---|---|---|
0281012985_9661204380_SW1037379394_MJ1037386115_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281012985_9661204380_SW1037379394_MJ1037386115_N3.zip (734 KB)
| File | Memory | Size |
|---|---|---|
0281012985_9661204380_SW1037379394_MJ1037386115_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012985_9661204380_SW1037379394_MJ1037386115_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 24 bytes differ in the flash (10 areas: 0x007FC4–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 443 bytes differ in the EEPROM (155 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
Read #3 compared with read #1: 24 bytes differ in the flash (10 areas: 0x007FC4–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 599 bytes differ in the EEPROM (186 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
EDC16C34 0281012985 1037379394 1037386115 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012985 – printed 0 281 012 985 on the label |
| PSA part number | 9661204380 – printed 96 612 043 80 |
| Software (SW) | 1037379394 – also written SW1037379394 |
| Upgrade / SW upg. | 1037386115 – also written MJ1037386115; your tool shows SW 1037379394 and SW upg. 1037386115 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 2.1 MB, instant download after payment |
Notes on this file
We read three EDC16C34 ECUs running software 1037379394 for this page. Hardware 0281012985 is known with 2 software versions in our catalogue; this page is 1037379394 updated to 1037386115. Engine: Citroën C4 1.6 HDi (110 hp, engine code 9HY).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 012 985 (hardware) and 96 612 043 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037379394 |
| SW upg. (SW màj., soft up, UpgSW) | 1037386115 |
Two numbers = this file: SW 1037379394 and SW upg. 1037386115. One number 1037386115 alone = still this file. 1037379394 twice = the factory read, sold on its own page.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037386115 | SW 1037379394 / SW upg. 1037386115 | C4 1.6 HDi | this file |
| upgrade 1037386114 | SW 1037379394 / SW upg. 1037386114 | C4 1.6 HDi | open |
| upgrade 1039398213 | SW 1037379394 / SW upg. 1039398213 | C4 1.6 HDi | open |
- Same hardware 0281012985: SW 1037386166 (PSA 9664843780) – 308 1.6 HDi
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011629 · 1037374179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012985 1037379394 1037386115 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037379394.
My tool shows SW 1037379394 and SW upg. 1037386115 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037386115, and 1037379394 is the base number the ECU still reports.
My tool shows only “SW upg. 1037386115” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281012985 and 9661204380 on the label and you are good.
Does it fit the Peugeot 207 1.6 HDi?
Yes – the 207 is confirmed for this software. Check 0 281 012 985 and 96 612 043 80 on the label and software 1037379394 in your tool before ordering.
Does it fit the Peugeot 307 1.6 HDi?
Yes – the 307 is confirmed for this software. Check 0 281 012 985 and 96 612 043 80 on the label and software 1037379394 in your tool before ordering.
Will this file work on a Citroën Berlingo?
Only if the Berlingo label reads HW 0281012985 / PSA 9661204380 and the tool shows 1037379394 / 1037386115. It is reported with this software but we did not read it from a Berlingo ourselves.
