EDC16C34 0281013871 1037386178 1037393472 – original full BDM backup from a Bosch EDC16C34 fitted to the Citroën Berlingo 1.6 HDi (PSA 9664618080): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (2 ZIPs, 1.5 MB in total)
✔ EDC16C34 0281013871 1037386178 1037393472 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën Berlingo 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as 2 ZIPs with an INFOS.html datasheet.
Moreover, the ZIP is delivered instantly once the order is paid.
Two independent reads of the same software, from two different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the other to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën Berlingo | 1.6 HDi | 9HX | 90 hp / 66 kW | confirmed for this software |
| Citroën C4 | 1.6 HDi | 9HV | 75 hp / 55 kW | confirmed for this software |
| Peugeot 308 | 1.6 HDi | 9HV | 75 hp / 55 kW | confirmed for this software |
| Peugeot Partner | 1.6 HDi | 9HX | 90 hp / 66 kW | twin model – same vehicle as the Citroën Berlingo, Peugeot badge |
| Peugeot Partner | 1.6 D | — | — | reported, not confirmed |
Do not rely on the model alone: check HW 0281013871 and PSA 9664618080 on the label, then 1037386178 and 1037393472 on the identification screen of your tool.
If your Berlingo shows HW 0281013871 but SW 1037383745 (PSA 9664618080), you need this other file instead.
Archive contents
Read #1 – 0281013871_9664618080_SW1037386178_MJ1037393472_N1.zip (751 KB)
| File | Memory | Size |
|---|---|---|
0281013871_9664618080_SW1037386178_MJ1037393472_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013871_9664618080_SW1037386178_MJ1037393472_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013871_9664618080_SW1037386178_MJ1037393472_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013871_9664618080_SW1037386178_MJ1037393472_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281013871_9664618080_SW1037386178_MJ1037393472_N2.zip (766 KB)
| File | Memory | Size |
|---|---|---|
0281013871_9664618080_SW1037386178_MJ1037393472_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013871_9664618080_SW1037386178_MJ1037393472_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013871_9664618080_SW1037386178_MJ1037393472_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013871_9664618080_SW1037386178_MJ1037393472_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 15 bytes differ in the flash (6 areas: 0x007FC4–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 503 bytes differ in the EEPROM (164 areas: 0x000001–0x000003, 0x00000B, 0x00000E, …).
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
EDC16C34 0281013871 1037386178 1037393472 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281013871 – printed 0 281 013 871 on the label |
| PSA part number | 9664618080 – printed 96 646 180 80 |
| Software (SW) | 1037386178 – also written SW1037386178 |
| Upgrade / SW upg. | 1037393472 – also written MJ1037393472; your tool shows SW 1037386178 and SW upg. 1037393472 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 1.5 MB, instant download after payment |
Notes on this file
We read two EDC16C34 ECUs running software 1037386178 for this page. Hardware 0281013871 is known with 2 software versions in our catalogue; this page is 1037386178 updated to 1037393472. Engine: Citroën Berlingo 1.6 HDi (90 hp, engine code 9HX).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 013 871 (hardware) and 96 646 180 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037386178 |
| SW upg. (SW màj., soft up, UpgSW) | 1037393472 |
Two numbers = this file: SW 1037386178 and SW upg. 1037393472. One number 1037393472 alone = still this file. 1037386178 twice = the factory read, sold on its own page.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037393472 | SW 1037386178 / SW upg. 1037393472 | Berlingo 1.6 HDi | this file |
| upgrade 1037389514 | SW 1037386178 / SW upg. 1037389514 | Berlingo 1.6 HDi | open |
| upgrade 1037393468 | SW 1037386178 / SW upg. 1037393468 | Berlingo 1.6 HDi | open |
| upgrade 1037393471 | SW 1037386178 / SW upg. 1037393471 | Berlingo 1.6 HDi | open |
| upgrade 1037393481 | SW 1037386178 / SW upg. 1037393481 | Berlingo 1.6 HDi | open |
| upgrade 1039398225 | SW 1037386178 / SW upg. 1039398225 | Berlingo 1.6 HDi | open |
- Same hardware 0281013871: SW 1037383745 (PSA 9664618080) – Berlingo 1.6 HDi
- Other Citroën Berlingo EDC16C34 files: 0281012619 · 1037375956 · 0281012620 · 1037377715 · 0281012619 · 1037380736 · 0281012620 · 1037383736 · 0281012619 · 1037386179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281013871 1037386178 1037393472 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën Berlingo 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037386178.
My tool shows SW 1037386178 and SW upg. 1037393472 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037393472, and 1037386178 is the base number the ECU still reports.
My tool shows only “SW upg. 1037393472” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281013871 and 9664618080 on the label and you are good.
Does it fit the Citroën C4 1.6 HDi?
Yes – the C4 is confirmed for this software. Check 0 281 013 871 and 96 646 180 80 on the label and software 1037386178 in your tool before ordering.
Does it fit the Peugeot 308 1.6 HDi?
Yes – the 308 is confirmed for this software. Check 0 281 013 871 and 96 646 180 80 on the label and software 1037386178 in your tool before ordering.
Will this file work on a Peugeot Partner 1.6 D?
Only if the Partner label reads HW 0281013871 / PSA 9664618080 and the tool shows 1037386178 / 1037393472. It is reported with this software but we did not read it from a Partner ourselves.
