EDC16C34 0281011629 1037374179 ORI: the unmodified full BDM backup of a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9658944580) – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) read on the bench.
What you get (ZIP, 646 KB)
✔ EDC16C34 0281011629 1037374179 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (646 KB) holding the software of a Bosch EDC16C34 read on the bench (Citroën C4 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | 9HY | 110 hp / 80 kW | 2004-2010 | confirmed for this software |
| Peugeot 307 | 1.6 HDi | — | 110 hp / 80 kW | — | confirmed for this software |
| Peugeot 308 | 1.6 HDi | 9HT | 110 hp / 80 kW | — | reported, not confirmed |
Two C4 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011629, PSA 9658944580 – and the software 1037374179 shown by your tool before ordering.
Same hardware 0281011629, different software 1037371536? That one is sold separately here.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011629_9658944580_SW1037374179_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011629_9658944580_SW1037374179_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011629_9658944580_SW1037374179_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011629_9658944580_SW1037374179_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011629 1037374179 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011629 – printed 0 281 011 629 on the label |
| PSA part number | 9658944580 – printed 96 589 445 80 |
| Software (SW) | 1037374179 – also written SW1037374179 |
| Upgrade / SW upg. | none – your tool shows 1037374179 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 646 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC16C34 (fichier d’origine in French, file ori in Italian).
Notes on this file
Hardware 0281011629 is known with 4 software versions in our catalogue; this page is 1037374179. Engine: Citroën C4 1.6 HDi (110 hp, engine code 9HY, 2004-2010).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 011 629 and the PSA number 96 589 445 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037374179 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037374179 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037374179 again |
Expected ID screen: SW 1037374179, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281011629: SW 1037371536 (PSA 9651132880) – C4 1.6 HDi · SW 1037376755 (PSA 9661377180) – C4 1.6 HDi · SW 1037386166 (PSA 9664843780) – 308 1.6 HDi
- Other Citroën C4 EDC16C34 files: 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011863 · 1037375526 · 0281011634 · 1037375534
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011629 1037374179 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037374179.
My tool shows SW 1037374179 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 629 and 96 589 445 80 on the label; if the upgrade line is empty or repeats 1037374179, this is your file.
Does it fit the Peugeot 307 1.6 HDi?
Yes – the 307 is confirmed for this software. Check 0 281 011 629 and 96 589 445 80 on the label and software 1037374179 in your tool before ordering.
Will this file work on a Peugeot 308 1.6 HDi?
Only if the 308 label reads HW 0281011629 / PSA 9658944580 and the tool shows 1037374179. It is reported with this software but we did not read it from a 308 ourselves.
Same hardware 0281011629 but my tool shows SW 1037371536?
Then you need the other file for this hardware: SW 1037371536 with PSA 9651132880, sold on its own page. 0281011629 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor C4?
Yes, as read. This is the original state of ECU 0281011629, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
