EDC16C34 0281011966 1037382268 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9662670780): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 669 KB)
✔ EDC16C34 0281011966 1037382268 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (669 KB) with the complete memory of a Bosch EDC16C34, read on the bench (Citroën C4 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Citroën C4 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
| Citroën C5 | 1.6 HDi | — | reported, not confirmed |
| Peugeot 206 | 1.9 D | — | reported, not confirmed |
| Peugeot 207 | 1.6 HDi | — | reported, not confirmed |
Two C4 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011966, PSA 9662670780 – and the software 1037382268 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011966_9662670780_SW1037382268_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011966_9662670780_SW1037382268_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011966_9662670780_SW1037382268_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011966_9662670780_SW1037382268_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011966 1037382268 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011966 – printed 0 281 011 966 on the label |
| PSA part number | 9662670780 – printed 96 626 707 80 |
| Software (SW) | 1037382268 – also written SW1037382268 |
| Upgrade / SW upg. | none – your tool shows 1037382268 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 669 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
Engine: Citroën C4 1.6 HDi (110 hp).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 011 966 and the PSA number 96 626 707 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037382268 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037382268 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037382268 again |
Your tool should show 1037382268 as SW and either nothing or 1037382268 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011629 · 1037374179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011966 1037382268 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037382268.
My tool shows SW 1037382268 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 966 and 96 626 707 80 on the label; if the upgrade line is empty or repeats 1037382268, this is your file.
Will this file work on a Citroën C5 1.6 HDi?
Only if the C5 label reads HW 0281011966 / PSA 9662670780 and the tool shows 1037382268. It is reported with this software but we did not read it from a C5 ourselves.
Does the EEPROM contain the immobiliser of the donor C4?
Yes, as read. This is the original state of ECU 0281011966, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
