EDC16C34 0281012620 1037377715 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Citroën Berlingo 1.6 HDi (PSA 9661813780): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (6 ZIPs, 4.1 MB in total)
✔ EDC16C34 0281012620 1037377715 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC16C34, read on the bench (Citroën Berlingo 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. In addition, the download link is available right after payment.
6 independent reads of the same software, from 6 different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën Berlingo | 1.6 HDi | 9HW | 75 hp / 55 kW | confirmed for this software |
| Peugeot Partner | 1.6 HDi | 9HW | 75 hp / 55 kW | twin model – same vehicle as the Citroën Berlingo, Peugeot badge |
Two Berlingo with the same engine can carry different software, so match the numbers on the ECU label – HW 0281012620, PSA 9661813780 – and the software 1037377715 shown by your tool before ordering.
Same hardware 0281012620, different software 1037383736? That one is sold separately here.
Archive contents
Read #1 – 0281012620_9661813780_SW1037377715_N1.zip (681 KB)
| File | Memory | Size |
|---|---|---|
0281012620_9661813780_SW1037377715_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012620_9661813780_SW1037377715_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012620_9661813780_SW1037377715_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012620_9661813780_SW1037377715_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281012620_9661813780_SW1037377715_N2.zip (696 KB)
| File | Memory | Size |
|---|---|---|
0281012620_9661813780_SW1037377715_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012620_9661813780_SW1037377715_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012620_9661813780_SW1037377715_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012620_9661813780_SW1037377715_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281012620_9661813780_SW1037377715_N3.zip (697 KB)
| File | Memory | Size |
|---|---|---|
0281012620_9661813780_SW1037377715_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012620_9661813780_SW1037377715_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012620_9661813780_SW1037377715_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012620_9661813780_SW1037377715_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #4 – 0281012620_9661813780_SW1037377715_N4.zip (697 KB)
| File | Memory | Size |
|---|---|---|
0281012620_9661813780_SW1037377715_N4_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012620_9661813780_SW1037377715_N4_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012620_9661813780_SW1037377715_N4_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012620_9661813780_SW1037377715_N4_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #5 – 0281012620_9661813780_SW1037377715_N5.zip (696 KB)
| File | Memory | Size |
|---|---|---|
0281012620_9661813780_SW1037377715_N5_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012620_9661813780_SW1037377715_N5_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012620_9661813780_SW1037377715_N5_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012620_9661813780_SW1037377715_N5_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #6 – 0281012620_9661813780_SW1037377715_N6.zip (697 KB)
| File | Memory | Size |
|---|---|---|
0281012620_9661813780_SW1037377715_N6_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012620_9661813780_SW1037377715_N6_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012620_9661813780_SW1037377715_N6_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012620_9661813780_SW1037377715_N6_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 14 bytes differ in the flash (3 areas: 0x007FC3–0x007FCB, 0x03FA86–0x03FA88, 0x03FAAE–0x03FAAF); 604 bytes differ in the EEPROM (135 areas: 0x000001–0x000003, 0x000011, 0x000021–0x000025, …).
Read #3 compared with read #1: 14 bytes differ in the flash (3 areas: 0x007FC3–0x007FCB, 0x03FA86–0x03FA88, 0x03FAAE–0x03FAAF); 579 bytes differ in the EEPROM (114 areas: 0x000001–0x000003, 0x000008, 0x00000B, …).
Read #4 compared with read #1: 14 bytes differ in the flash (3 areas: 0x007FC3–0x007FCB, 0x03FA86–0x03FA88, 0x03FAAE–0x03FAAF); 523 bytes differ in the EEPROM (138 areas: 0x000001–0x000003, 0x000008, 0x00000A–0x00000B, …).
Read #5 compared with read #1: 10 bytes differ in the flash (5 areas: 0x007FC4, 0x007FC6–0x007FC7, 0x007FC9–0x007FCB, …); 552 bytes differ in the EEPROM (138 areas: 0x000001–0x000003, 0x00000B, 0x00000D, …).
Read #6 compared with read #1: 14 bytes differ in the flash (3 areas: 0x007FC3–0x007FCB, 0x03FA86–0x03FA88, 0x03FAAE–0x03FAAF); 534 bytes differ in the EEPROM (129 areas: 0x000001–0x000003, 0x000008, 0x00000B, …).
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281012620 1037377715 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012620 – printed 0 281 012 620 on the label |
| PSA part number | 9661813780 – printed 96 618 137 80 |
| Software (SW) | 1037377715 – also written SW1037377715 |
| Upgrade / SW upg. | none – your tool shows 1037377715 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 4.1 MB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
We read 6 EDC16C34 ECUs running software 1037377715 for this page. Hardware 0281012620 is known with 3 software versions in our catalogue; this page is 1037377715. Engine: Citroën Berlingo 1.6 HDi (75 hp, engine code 9HW).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 012 620 and 96 618 137 80. The 1039S… sticker is not a software number – 1037377715 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037377715 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037377715 again |
Expected ID screen: SW 1037377715, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281012620: SW 1037383736 (PSA 9663944680) – Berlingo 1.6 HDi · SW 1037391702 (PSA 9665594380) – Berlingo 1.6 HDi
- Other Citroën Berlingo EDC16C34 files: 0281012619 · 1037375956 · 0281012619 · 1037380736 · 0281013871 · 1037383745 upg. 1037389514 · 0281013871 · 1037386178 upg. 1037389514 · 0281013871 · 1037386178 upg. 1037393468
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012620 1037377715 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën Berlingo 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037377715.
My tool shows SW 1037377715 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 012 620 and 96 618 137 80 on the label; if the upgrade line is empty or repeats 1037377715, this is your file.
Does it fit the Peugeot Partner 1.6 HDi?
Yes – the Partner is the twin of the Citroën Berlingo: same engine, same EDC16C34. Check 0 281 012 620 and 96 618 137 80 on the label and software 1037377715 in your tool before ordering.
Same hardware 0281012620 but my tool shows SW 1037383736?
Then you need the other file for this hardware: SW 1037383736 with PSA 9663944680, sold on its own page. 0281012620 alone is not enough to choose.
Why are there 6 downloads for one software?
We read 6 ECUs running 1037377715. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor Berlingo?
Yes, as read. This is the original state of ECU 0281012620, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
