EDC16C34 0281014729 1037386171 1039398210 is the original full BDM backup of a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9665674480): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 749 KB)
✔ EDC16C34 0281014729 1037386171 1039398210 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën C4 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | 9HZ | 109 hp / 80 kW | confirmed for this software |
| Citroën C4 PICASSO | 1.6 HDi | — | 109 hp / 80 kW | confirmed for this software |
| Peugeot 3008 | 1.6 HDi | 9HZ | 110 hp / 80 kW | confirmed for this software |
| Peugeot 407 | 1.6 HDi | — | — | reported, not confirmed |
| Peugeot 5008 | 1.6 HDi | — | — | reported, not confirmed |
Two C4 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281014729, PSA 9665674480 – and the software 1037386171 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281014729_9665674480_SW1037386171_MJ1039398210_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281014729_9665674480_SW1037386171_MJ1039398210_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281014729_9665674480_SW1037386171_MJ1039398210_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281014729_9665674480_SW1037386171_MJ1039398210_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
EDC16C34 0281014729 1037386171 1039398210 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281014729 – printed 0 281 014 729 on the label |
| PSA part number | 9665674480 – printed 96 656 744 80 |
| Software (SW) | 1037386171 – also written SW1037386171 |
| Upgrade / SW upg. | 1039398210 – also written MJ1039398210; your tool shows SW 1037386171 and SW upg. 1039398210 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 749 KB, instant download after payment |
Notes on this file
Engine: Citroën C4 1.6 HDi (109 hp, engine code 9HZ).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 014 729 (hardware) and 96 656 744 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037386171 |
| SW upg. (SW màj., soft up, UpgSW) | 1039398210 |
Look for the pair 1037386171 / 1039398210 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1039398210 alone, points to this file; 1037386171 twice points to the non-updated read.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1039398210 | SW 1037386171 / SW upg. 1039398210 | C4 1.6 HDi | this file |
| upgrade 1037393495 | SW 1037386171 / SW upg. 1037393495 | C4 1.6 HDi | open |
| upgrade 1037393496 | SW 1037386171 / SW upg. 1037393496 | C4 1.6 HDi | open |
| upgrade 1037395384 | SW 1037386171 / SW upg. 1037395384 | C4 1.6 HDi | open |
| upgrade 1037395385 | SW 1037386171 / SW upg. 1037395385 | C4 1.6 HDi | open |
| upgrade 1037398202 | SW 1037386171 / SW upg. 1037398202 | C4 1.6 HDi | open |
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011629 · 1037374179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281014729 1037386171 1039398210 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037386171.
My tool shows SW 1037386171 and SW upg. 1039398210 – is this the file?
Yes, exactly this one: the flash holds the updated software 1039398210, and 1037386171 is the base number the ECU still reports.
My tool shows only “SW upg. 1039398210” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281014729 and 9665674480 on the label and you are good.
Does it fit the Citroën C4 PICASSO 1.6 HDi?
Yes – the C4 PICASSO is confirmed for this software. Check 0 281 014 729 and 96 656 744 80 on the label and software 1037386171 in your tool before ordering.
Does it fit the Peugeot 3008 1.6 HDi?
Yes – the 3008 is confirmed for this software. Check 0 281 014 729 and 96 656 744 80 on the label and software 1037386171 in your tool before ordering.
Will this file work on a Peugeot 407 1.6 HDi?
Only if the 407 label reads HW 0281014729 / PSA 9665674480 and the tool shows 1037386171 / 1039398210. It is reported with this software but we did not read it from a 407 ourselves.
