EDC16C34 0281011629 1037376755 ORI: the unmodified full BDM backup of a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9661377180) – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) read on the bench.
What you get (ZIP, 650 KB)
✔ EDC16C34 0281011629 1037376755 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën C4 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | 9HY | 110 hp / 80 kW | 2004-2010 | confirmed for this software |
| Peugeot 307 | 1.6 HDi | — | 110 hp / 80 kW | — | confirmed for this software |
| Peugeot 308 | 1.6 HDi | 9HT | 110 hp / 80 kW | — | reported, not confirmed |
Do not rely on the model alone: check HW 0281011629 and PSA 9661377180 on the label, then 1037376755 on the identification screen of your tool.
With HW 0281011629 but PSA 9651132880 / SW 1037371536, take that file.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011629_9661377180_SW1037376755_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011629_9661377180_SW1037376755_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011629_9661377180_SW1037376755_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011629_9661377180_SW1037376755_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011629 1037376755 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011629 – printed 0 281 011 629 on the label |
| PSA part number | 9661377180 – printed 96 613 771 80 |
| Software (SW) | 1037376755 – also written SW1037376755 |
| Upgrade / SW upg. | none – your tool shows 1037376755 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 650 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Hardware 0281011629 is known with 4 software versions in our catalogue; this page is 1037376755. Engine: Citroën C4 1.6 HDi (110 hp, engine code 9HY, 2004-2010).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 011 629 and the PSA number 96 613 771 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037376755 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037376755 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037376755 again |
Your tool should show 1037376755 as SW and either nothing or 1037376755 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281011629: SW 1037371536 (PSA 9651132880) – C4 1.6 HDi · SW 1037374179 (PSA 9658944580) – C4 1.6 HDi · SW 1037386166 (PSA 9664843780) – 308 1.6 HDi
- Other Citroën C4 EDC16C34 files: 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011863 · 1037375526 · 0281011634 · 1037375534
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011629 1037376755 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037376755.
My tool shows SW 1037376755 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 629 and 96 613 771 80 on the label; if the upgrade line is empty or repeats 1037376755, this is your file.
Does it fit the Peugeot 307 1.6 HDi?
Yes – the 307 is confirmed for this software. Check 0 281 011 629 and 96 613 771 80 on the label and software 1037376755 in your tool before ordering.
Will this file work on a Peugeot 308 1.6 HDi?
Only if the 308 label reads HW 0281011629 / PSA 9661377180 and the tool shows 1037376755. It is reported with this software but we did not read it from a 308 ourselves.
Same hardware 0281011629 but my tool shows SW 1037371536?
Then you need the other file for this hardware: SW 1037371536 with PSA 9651132880, sold on its own page. 0281011629 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor C4?
Yes, as read. This is the original state of ECU 0281011629, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
