EDC16C34 0281014729 1037386171 1037395384 – original full BDM backup from a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9665674480): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (2 ZIPs, 1.5 MB in total)
✔ EDC16C34 0281014729 1037386171 1037395384 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC16C34, read on the bench (Citroën C4 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
In addition, the download link is available right after payment.
Two independent reads of the same software, from two different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the other to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | 9HZ | 109 hp / 80 kW | — | confirmed for this software |
| Citroën C4 PICASSO | 1.6 HDi | — | 110 hp / 80 kW | — | confirmed for this software |
| Peugeot 3008 | 1.6 HDi | 9HZ | 110 hp / 80 kW | — | confirmed for this software |
| Peugeot 5008 | 1.6 HDi | — | 110 hp / 80 kW | — | confirmed for this software |
| Peugeot 307 | 1.6 HDi | 9HY | 90 hp / 66 kW | 2000-2009 | reported, not confirmed |
| Peugeot 308 | 1.6 HDi | 9HT | 110 hp / 80 kW | — | reported, not confirmed |
| Peugeot 407 | 1.6 HDi | — | — | — | reported, not confirmed |
Do not rely on the model alone: check HW 0281014729 and PSA 9665674480 on the label, then 1037386171 and 1037395384 on the identification screen of your tool.
With HW 0281014729 but PSA 9664843780 / SW 1037386166, take that file.
Archive contents
Read #1 – 0281014729_9665674480_SW1037386171_MJ1037395384_N1.zip (753 KB)
| File | Memory | Size |
|---|---|---|
0281014729_9665674480_SW1037386171_MJ1037395384_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281014729_9665674480_SW1037386171_MJ1037395384_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281014729_9665674480_SW1037386171_MJ1037395384_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281014729_9665674480_SW1037386171_MJ1037395384_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281014729_9665674480_SW1037386171_MJ1037395384_N2.zip (768 KB)
| File | Memory | Size |
|---|---|---|
0281014729_9665674480_SW1037386171_MJ1037395384_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281014729_9665674480_SW1037386171_MJ1037395384_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281014729_9665674480_SW1037386171_MJ1037395384_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281014729_9665674480_SW1037386171_MJ1037395384_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 16 bytes differ in the flash (6 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 548 bytes differ in the EEPROM (171 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
EDC16C34 0281014729 1037386171 1037395384 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281014729 – printed 0 281 014 729 on the label |
| PSA part number | 9665674480 – printed 96 656 744 80 |
| Software (SW) | 1037386171 – also written SW1037386171 |
| Upgrade / SW upg. | 1037395384 – also written MJ1037395384; your tool shows SW 1037386171 and SW upg. 1037395384 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 1.5 MB, instant download after payment |
Notes on this file
We read two EDC16C34 ECUs running software 1037386171 for this page. Hardware 0281014729 is known with 2 software versions in our catalogue; this page is 1037386171 updated to 1037395384. Engine: Citroën C4 1.6 HDi (109 hp, engine code 9HZ).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 014 729 and the PSA number 96 656 744 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037386171 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.

What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037386171 |
| SW upg. (SW màj., soft up, UpgSW) | 1037395384 |
Two numbers = this file: SW 1037386171 and SW upg. 1037395384. One number 1037395384 alone = still this file. 1037386171 twice = the factory read, sold on its own page.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037395384 | SW 1037386171 / SW upg. 1037395384 | C4 1.6 HDi | this file |
| upgrade 1037393495 | SW 1037386171 / SW upg. 1037393495 | C4 1.6 HDi | open |
| upgrade 1037393496 | SW 1037386171 / SW upg. 1037393496 | C4 1.6 HDi | open |
| upgrade 1037395385 | SW 1037386171 / SW upg. 1037395385 | C4 1.6 HDi | open |
| upgrade 1037395388 | SW 1037386171 / SW upg. 1037395388 | C4 1.6 HDi | open |
| upgrade 1037398202 | SW 1037386171 / SW upg. 1037398202 | C4 1.6 HDi | open |
- Same hardware 0281014729: SW 1037386166 (PSA 9664843780) – 308 1.6 HDi
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011629 · 1037374179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281014729 1037386171 1037395384 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037386171.
My tool shows SW 1037386171 and SW upg. 1037395384 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037395384, and 1037386171 is the base number the ECU still reports.
My tool shows only “SW upg. 1037395384” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281014729 and 9665674480 on the label and you are good.
Does it fit the Citroën C4 PICASSO 1.6 HDi?
Yes – the C4 PICASSO is confirmed for this software. Check 0 281 014 729 and 96 656 744 80 on the label and software 1037386171 in your tool before ordering.
Does it fit the Peugeot 3008 1.6 HDi?
Yes – the 3008 is confirmed for this software. Check 0 281 014 729 and 96 656 744 80 on the label and software 1037386171 in your tool before ordering.
Will this file work on a Peugeot 307 1.6 HDi?
Only if the 307 label reads HW 0281014729 / PSA 9665674480 and the tool shows 1037386171 / 1037395384. It is reported with this software but we did not read it from a 307 ourselves.
