EDC16C34 0281013331 1037380086 1037386138 is the original full BDM backup of a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9662213180): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (3 ZIPs, 2.2 MB in total)
✔ EDC16C34 0281013331 1037380086 1037386138 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën C4 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as 3 ZIPs with an INFOS.html datasheet.
In addition, the download link is available right after payment.
Three independent reads of the same software, from three different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | 9HZ | 110 hp / 80 kW | confirmed for this software |
| Peugeot 307 | 1.6 HDi | 9HZ | 110 hp / 80 kW | confirmed for this software |
| Peugeot 207 | 1.6 HDi | — | — | reported, not confirmed |
Do not rely on the model alone: check HW 0281013331 and PSA 9662213180 on the label, then 1037380086 and 1037386138 on the identification screen of your tool.
Archive contents
Read #1 – 0281013331_9662213180_SW1037380086_MJ1037386138_N1.zip (731 KB)
| File | Memory | Size |
|---|---|---|
0281013331_9662213180_SW1037380086_MJ1037386138_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281013331_9662213180_SW1037380086_MJ1037386138_N2.zip (746 KB)
| File | Memory | Size |
|---|---|---|
0281013331_9662213180_SW1037380086_MJ1037386138_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281013331_9662213180_SW1037380086_MJ1037386138_N3.zip (746 KB)
| File | Memory | Size |
|---|---|---|
0281013331_9662213180_SW1037380086_MJ1037386138_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013331_9662213180_SW1037380086_MJ1037386138_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 20 bytes differ in the flash (5 areas: 0x007FC2–0x007FCB, 0x03FA86–0x03FA88, 0x03FAAE–0x03FAAF, …); 509 bytes differ in the EEPROM (169 areas: 0x000001–0x000003, 0x000008, 0x00000A–0x00000B, …).
Read #3 compared with read #1: 20 bytes differ in the flash (5 areas: 0x007FC2–0x007FCB, 0x03FA86–0x03FA88, 0x03FAAE–0x03FAAF, …); 552 bytes differ in the EEPROM (170 areas: 0x000001–0x000003, 0x000008, 0x00000A–0x00000B, …).
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
EDC16C34 0281013331 1037380086 1037386138 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281013331 – printed 0 281 013 331 on the label |
| PSA part number | 9662213180 – printed 96 622 131 80 |
| Software (SW) | 1037380086 – also written SW1037380086 |
| Upgrade / SW upg. | 1037386138 – also written MJ1037386138; your tool shows SW 1037380086 and SW upg. 1037386138 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 2.2 MB, instant download after payment |
Notes on this file
We read three EDC16C34 ECUs running software 1037380086 for this page. Engine: Citroën C4 1.6 HDi (110 hp, engine code 9HZ).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 013 331 (hardware) and 96 622 131 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037380086 |
| SW upg. (SW màj., soft up, UpgSW) | 1037386138 |
Look for the pair 1037380086 / 1037386138 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1037386138 alone, points to this file; 1037380086 twice points to the non-updated read.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037386138 | SW 1037380086 / SW upg. 1037386138 | C4 1.6 HDi | this file |
| upgrade 1037381871 | SW 1037380086 / SW upg. 1037381871 | C4 1.6 HDi | open |
| upgrade 1037386114 | SW 1037380086 / SW upg. 1037386114 | C4 1.6 HDi | open |
| upgrade 1037386115 | SW 1037380086 / SW upg. 1037386115 | C4 1.6 HDi | open |
| upgrade 1037386118 | SW 1037380086 / SW upg. 1037386118 | C4 1.6 HDi | open |
| upgrade 1039398213 | SW 1037380086 / SW upg. 1039398213 | C4 1.6 HDi | open |
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011629 · 1037374179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281013331 1037380086 1037386138 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037380086.
My tool shows SW 1037380086 and SW upg. 1037386138 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037386138, and 1037380086 is the base number the ECU still reports.
My tool shows only “SW upg. 1037386138” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281013331 and 9662213180 on the label and you are good.
Does it fit the Peugeot 307 1.6 HDi?
Yes – the 307 is confirmed for this software. Check 0 281 013 331 and 96 622 131 80 on the label and software 1037380086 in your tool before ordering.
Will this file work on a Peugeot 207 1.6 HDi?
Only if the 207 label reads HW 0281013331 / PSA 9662213180 and the tool shows 1037380086 / 1037386138. It is reported with this software but we did not read it from a 207 ourselves.
