EDC16C34 0281011630 1037372085 1037380728 – original full BDM backup from a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9656840980): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (ZIP, 686 KB)
✔ EDC16C34 0281011630 1037372085 1037380728 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën C4 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | DV6TED4 | 109 hp / 80 kW | confirmed for this software |
Do not rely on the model alone: check HW 0281011630 and PSA 9656840980 on the label, then 1037372085 and 1037380728 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011630_9656840980_SW1037372085_MJ1037380728_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011630_9656840980_SW1037372085_MJ1037380728_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011630_9656840980_SW1037372085_MJ1037380728_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011630_9656840980_SW1037372085_MJ1037380728_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
EDC16C34 0281011630 1037372085 1037380728 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011630 – printed 0 281 011 630 on the label |
| PSA part number | 9656840980 – printed 96 568 409 80 |
| Software (SW) | 1037372085 – also written SW1037372085 |
| Upgrade / SW upg. | 1037380728 – also written MJ1037380728; your tool shows SW 1037372085 and SW upg. 1037380728 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 686 KB, instant download after payment |
Notes on this file
Engine: Citroën C4 1.6 HDi (109 hp, engine code DV6TED4).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 011 630 (hardware) and 96 568 409 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037372085 |
| SW upg. (SW màj., soft up, UpgSW) | 1037380728 |
Look for the pair 1037372085 / 1037380728 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1037380728 alone, points to this file; 1037372085 twice points to the non-updated read.
Other files you may need
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011629 · 1037374179 · 0281011863 · 1037375526
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011630 1037372085 1037380728 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037372085.
My tool shows SW 1037372085 and SW upg. 1037380728 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037380728, and 1037372085 is the base number the ECU still reports.
My tool shows only “SW upg. 1037380728” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281011630 and 9656840980 on the label and you are good.
Will this file work on a Peugeot 207?
Only if the 207 label reads HW 0281011630 / PSA 9656840980 and the tool shows 1037372085 / 1037380728. It is reported with this software but we did not read it from a 207 ourselves.
