EDC16C34 0281012980 1037380743 1037389513 – original full BDM backup from a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9663476180): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (ZIP, 699 KB)
✔ EDC16C34 0281012980 1037380743 1037389513 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën C4 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Citroën C4 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
| Citroën C4 PICASSO | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
| Citroën C4 PICASSO | — | 109 hp / 80 kW | confirmed for this software |
Do not rely on the model alone: check HW 0281012980 and PSA 9663476180 on the label, then 1037380743 and 1037389513 on the identification screen of your tool.
If your C4 shows HW 0281012980 but SW 1037386155 (PSA 9664617480), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012980_9663476180_SW1037380743_MJ1037389513_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012980_9663476180_SW1037380743_MJ1037389513_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012980_9663476180_SW1037380743_MJ1037389513_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012980_9663476180_SW1037380743_MJ1037389513_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
EDC16C34 0281012980 1037380743 1037389513 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012980 – printed 0 281 012 980 on the label |
| PSA part number | 9663476180 – printed 96 634 761 80 |
| Software (SW) | 1037380743 – also written SW1037380743 |
| Upgrade / SW upg. | 1037389513 – also written MJ1037389513; your tool shows SW 1037380743 and SW upg. 1037389513 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 699 KB, instant download after payment |
Notes on this file
Hardware 0281012980 is known with 2 software versions in our catalogue; this page is 1037380743 updated to 1037389513. Engine: Citroën C4 1.6 HDi (110 hp).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 012 980 and the PSA number 96 634 761 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037380743 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037380743 |
| SW upg. (SW màj., soft up, UpgSW) | 1037389513 |
Look for the pair 1037380743 / 1037389513 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1037389513 alone, points to this file; 1037380743 twice points to the non-updated read.
Other files you may need
- Same hardware 0281012980: SW 1037386155 (PSA 9664617480) – C4 1.6 HDi
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011629 · 1037374179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012980 1037380743 1037389513 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037380743.
My tool shows SW 1037380743 and SW upg. 1037389513 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037389513, and 1037380743 is the base number the ECU still reports.
My tool shows only “SW upg. 1037389513” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281012980 and 9663476180 on the label and you are good.
Same hardware 0281012980 but my tool shows SW 1037386155?
Then you need the other file for this hardware: SW 1037386155 with PSA 9664617480, sold on its own page. 0281012980 alone is not enough to choose.
