EDC16C34 0281012981 1037380744 1037389516 – original full BDM backup from a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9663476380): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (ZIP, 694 KB)
✔ EDC16C34 0281012981 1037380744 1037389516 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën C4 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | 9HZ | 110 hp / 80 kW | confirmed for this software |
| Citroën C4 PICASSO | 1.6 HDi | DV6TED | 110 hp / 80 kW | confirmed for this software |
| Citroën C4 PICASSO | 1.4 HDi | — | — | reported, not confirmed |
| Peugeot 207 | 1.6 HDi | 9HX | 90 hp / 66 kW | reported, not confirmed |
Hardware 0281012981 was fitted with 3 software states in our catalogue, so the engine badge is not enough: compare HW 0281012981 and PSA 9663476380 on the label, then the software numbers in your tool.
With HW 0281012981 but PSA 9662212480 / SW 1037379395, take that file.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012981_9663476380_SW1037380744_MJ1037389516_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012981_9663476380_SW1037380744_MJ1037389516_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012981_9663476380_SW1037380744_MJ1037389516_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012981_9663476380_SW1037380744_MJ1037389516_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
EDC16C34 0281012981 1037380744 1037389516 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012981 – printed 0 281 012 981 on the label |
| PSA part number | 9663476380 – printed 96 634 763 80 |
| Software (SW) | 1037380744 – also written SW1037380744 |
| Upgrade / SW upg. | 1037389516 – also written MJ1037389516; your tool shows SW 1037380744 and SW upg. 1037389516 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 694 KB, instant download after payment |
Notes on this file
Hardware 0281012981 is known with 3 software versions in our catalogue; this page is 1037380744 updated to 1037389516. Engine: Citroën C4 1.6 HDi (110 hp, engine code 9HZ).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 012 981 (hardware) and 96 634 763 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037380744 |
| SW upg. (SW màj., soft up, UpgSW) | 1037389516 |
Two numbers = this file: SW 1037380744 and SW upg. 1037389516. One number 1037389516 alone = still this file. 1037380744 twice = the factory read, sold on its own page.
Other files you may need
- Same hardware 0281012981: SW 1037379395 (PSA 9662212480) – 207 1.6 HDi · SW 1037386157 (PSA 9664617680) – C4 1.6 HDi
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011629 · 1037374179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012981 1037380744 1037389516 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037380744.
My tool shows SW 1037380744 and SW upg. 1037389516 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037389516, and 1037380744 is the base number the ECU still reports.
My tool shows only “SW upg. 1037389516” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281012981 and 9663476380 on the label and you are good.
Will this file work on a Citroën C4 PICASSO 1.4 HDi?
Only if the C4 PICASSO label reads HW 0281012981 / PSA 9663476380 and the tool shows 1037380744 / 1037389516. It is reported with this software but we did not read it from a C4 PICASSO ourselves.
