EDC16C3 0281011234 1037370639 1037372090: the unmodified full BDM backup of a Bosch EDC16C3 fitted to the Peugeot 307 1.6 HDi (PSA 9689230080) – external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB read on the bench.
What you get (ZIP, 633 KB)
✔ EDC16C3 0281011234 1037370639 1037372090 full BDM backup – external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB, read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C3 used in the Peugeot 307 1.6 HDi: external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Peugeot 307 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
Do not rely on the model alone: check HW 0281011234 and PSA 9689230080 on the label, then 1037370639 and 1037372090 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011234_9689230080_SW1037370639_MJ1037372090_FLASH.bin | External flash | 1 048 576 bytes (1 MB) |
0281011234_9689230080_SW1037370639_MJ1037372090_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011234_9689230080_SW1037370639_MJ1037372090_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011234_9689230080_SW1037370639_MJ1037372090_MPC.bin | Internal flash (MPC) | 459 008 bytes (448 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in two formats for multi-tool compatibility – 2 KB / 4 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
EDC16C3 0281011234 1037370639 1037372090 – references
| ECU | Bosch EDC16C3 |
| Bosch hardware (HW) | 0281011234 – printed 0 281 011 234 on the label |
| PSA part number | 9689230080 – printed 96 892 300 80 |
| Software (SW) | 1037370639 – also written SW1037370639 |
| Upgrade / SW upg. | 1037372090 – also written MJ1037372090; your tool shows SW 1037370639 and SW upg. 1037372090 |
| Memory supplied | External flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 633 KB, instant download after payment |
Notes on this file
Engine: Peugeot 307 1.6 HDi (110 hp).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C3. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 011 234 and 96 892 300 80. The 1039S… sticker is not a software number – 1037370639 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037370639 |
| SW upg. (SW màj., soft up, UpgSW) | 1037372090 |
Two numbers = this file: SW 1037370639 and SW upg. 1037372090. One number 1037372090 alone = still this file. 1037370639 twice = the factory read, sold on its own page.
Other files you may need
- Other Peugeot 307 EDC16C3 files: 0281010390 · 1037351981 · 0281010390 · 1037366511 · 0281011090 · 1037370239 · 0281011558 · 1037370763 upg. 1037374181
- Bosch EDC16C3 family: all EDC16C3 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C3 0281011234 1037370639 1037372090 a full BDM backup or only the flash?
Full backup: the 1 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 307 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037370639.
My tool shows SW 1037370639 and SW upg. 1037372090 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037372090, and 1037370639 is the base number the ECU still reports.
My tool shows only “SW upg. 1037372090” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C3. Confirm 0281011234 and 9689230080 on the label and you are good.
Does the EEPROM contain the immobiliser of the donor 307?
Yes, as read. This is the original state of ECU 0281011234, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
