EDC16C3 0281010390 1037351981 ORI – original full BDM backup from a Bosch EDC16C3 fitted to the Peugeot 307 1.4 HDi (PSA 9646313280): external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB, bench read, nothing modified.
What you get (ZIP, 467 KB)
✔ EDC16C3 0281010390 1037351981 ORI full BDM backup – external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB, read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C3 used in the Peugeot 307 1.4 HDi: external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 307 | 1.4 HDi | 8HZ | 68 hp / 50 kW | confirmed for this software |
| Peugeot 206 | 1.4 HDi | — | — | reported, not confirmed |
| Peugeot 307 | 1.4 HDİ | — | — | reported, not confirmed |
| Peugeot 406 | 2.0 HDi | — | — | reported, not confirmed |
Two 307 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010390, PSA 9646313280 – and the software 1037351981 shown by your tool before ordering.
Same hardware 0281010390, different software 1037366511? That one is sold separately here.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010390_9646313280_SW1037351981_FLASH.bin | External flash | 1 048 576 bytes (1 MB) |
0281010390_9646313280_SW1037351981_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281010390_9646313280_SW1037351981_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281010390_9646313280_SW1037351981_MPC.bin | Internal flash (MPC) | 459 008 bytes (448 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Multi-tool ready: the EEPROM comes in two formats (2 KB / 4 KB), same content. 2 KB is native; pick the size your tool asks for.
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is included as well (448 KB).
EDC16C3 0281010390 1037351981 ORI – references
| ECU | Bosch EDC16C3 |
| Bosch hardware (HW) | 0281010390 – printed 0 281 010 390 on the label |
| PSA part number | 9646313280 – printed 96 463 132 80 |
| Software (SW) | 1037351981 – also written SW1037351981 |
| Upgrade / SW upg. | none – your tool shows 1037351981 in both fields, or leaves the second one empty |
| Memory supplied | External flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 467 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
Hardware 0281010390 is known with 2 software versions in our catalogue; this page is 1037351981. Engine: Peugeot 307 1.4 HDi (68 hp, engine code 8HZ).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C3 housing shows the hardware number 0 281 010 390 and the PSA number 96 463 132 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037351981 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037351981 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037351981 again |
Expected ID screen: SW 1037351981, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281010390: SW 1037366511 (PSA 9647158180) – 307 1.4 HDi
- Other Peugeot 307 EDC16C3 files: 0281011090 · 1037370239 · 0281011234 · 1037370639 upg. 1037372090 · 0281011558 · 1037370763 upg. 1037374181
- Bosch EDC16C3 family: all EDC16C3 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C3 0281010390 1037351981 ORI a full BDM backup or only the flash?
Full backup: the 1 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 307 1.4 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037351981.
My tool shows SW 1037351981 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 390 and 96 463 132 80 on the label; if the upgrade line is empty or repeats 1037351981, this is your file.
Will this file work on a Peugeot 206 1.4 HDi?
Only if the 206 label reads HW 0281010390 / PSA 9646313280 and the tool shows 1037351981. It is reported with this software but we did not read it from a 206 ourselves.
Same hardware 0281010390 but my tool shows SW 1037366511?
Then you need the other file for this hardware: SW 1037366511 with PSA 9647158180, sold on its own page. 0281010390 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 307?
Yes, as read. This is the original state of ECU 0281010390, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
