EDC16C34 0281011634 1037380082 1037380726 is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 307 1.6 HDi (PSA 9662872280): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (3 ZIPs, 2 MB in total)
✔ EDC16C34 0281011634 1037380082 1037380726 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive holding the updated software of a Bosch EDC16C34 read on the bench (Peugeot 307 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
Moreover, the ZIP is delivered instantly once the order is paid.
Three independent reads of the same software, from three different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 307 | 1.6 HDi | 9HX | 110 hp / 80 kW | confirmed for this software |
| Citroën C4 | 1.6 HDi | — | — | reported, not confirmed |
| Peugeot 306 | 1.6 HDi | — | — | reported, not confirmed |
Two 307 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011634, PSA 9662872280 – and the software 1037380082 shown by your tool before ordering.
With HW 0281011634 but PSA 9660324180 / SW 1037375534, take that file.
Archive contents
Read #1 – 0281011634_9662872280_SW1037380082_MJ1037380726_N1.zip (688 KB)
| File | Memory | Size |
|---|---|---|
0281011634_9662872280_SW1037380082_MJ1037380726_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011634_9662872280_SW1037380082_MJ1037380726_N2.zip (704 KB)
| File | Memory | Size |
|---|---|---|
0281011634_9662872280_SW1037380082_MJ1037380726_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281011634_9662872280_SW1037380082_MJ1037380726_N3.zip (704 KB)
| File | Memory | Size |
|---|---|---|
0281011634_9662872280_SW1037380082_MJ1037380726_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011634_9662872280_SW1037380082_MJ1037380726_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 15 bytes differ in the flash (6 areas: 0x007FC4–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 556 bytes differ in the EEPROM (143 areas: 0x000001–0x000003, 0x00000B, 0x00000E, …).
Read #3 compared with read #1: 16 bytes differ in the flash (6 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 575 bytes differ in the EEPROM (171 areas: 0x000001–0x000003, 0x00000B, 0x00000D–0x00000E, …).
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
EDC16C34 0281011634 1037380082 1037380726 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011634 – printed 0 281 011 634 on the label |
| PSA part number | 9662872280 – printed 96 628 722 80 |
| Software (SW) | 1037380082 – also written SW1037380082 |
| Upgrade / SW upg. | 1037380726 – also written MJ1037380726; your tool shows SW 1037380082 and SW upg. 1037380726 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 2 MB, instant download after payment |
Notes on this file
We read three EDC16C34 ECUs running software 1037380082 for this page. Hardware 0281011634 is known with 2 software versions in our catalogue; this page is 1037380082 updated to 1037380726. Engine: Peugeot 307 1.6 HDi (110 hp, engine code 9HX).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 011 634 and 96 628 722 80. The 1039S… sticker is not a software number – 1037380082 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037380082 |
| SW upg. (SW màj., soft up, UpgSW) | 1037380726 |
Two numbers = this file: SW 1037380082 and SW upg. 1037380726. One number 1037380726 alone = still this file. 1037380082 twice = the factory read, sold on its own page.
Other files you may need
- Same hardware 0281011634: SW 1037375534 (PSA 9660324180) – C4 1.6 HDi · SW 1037375534 (PSA 9660324180) – C4 1.6 HDi
- Other Peugeot 307 EDC16C34 files: 0281011627 · 1037369860 · 0281011627 · 1037371081 · 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011634 1037380082 1037380726 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 307 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037380082.
My tool shows SW 1037380082 and SW upg. 1037380726 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037380726, and 1037380082 is the base number the ECU still reports.
My tool shows only “SW upg. 1037380726” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281011634 and 9662872280 on the label and you are good.
Will this file work on a Citroën C4 1.6 HDi?
Only if the C4 label reads HW 0281011634 / PSA 9662872280 and the tool shows 1037380082 / 1037380726. It is reported with this software but we did not read it from a C4 ourselves.
