EDC16C3 0281010390 1037366511 ORI – original full BDM backup from a Bosch EDC16C3 fitted to the Peugeot 307 1.4 HDi (PSA 9647158180): external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB, bench read, nothing modified.
What you get (ZIP, 533 KB)
✔ EDC16C3 0281010390 1037366511 ORI full BDM backup – external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB, read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (533 KB) holding the software of a Bosch EDC16C3 read on the bench (Peugeot 307 1.4 HDi application): external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB from the same unit, with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 307 | 1.4 HDi | 8HZ | 68 hp / 50 kW | confirmed for this software |
Two 307 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010390, PSA 9647158180 – and the software 1037366511 shown by your tool before ordering.
Same hardware 0281010390, different software 1037351981? That one is sold separately here.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010390_9647158180_SW1037366511_FLASH.bin | External flash | 1 048 576 bytes (1 MB) |
0281010390_9647158180_SW1037366511_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281010390_9647158180_SW1037366511_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281010390_9647158180_SW1037366511_MPC.bin | Internal flash (MPC) | 459 008 bytes (448 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Multi-tool ready: the EEPROM comes in two formats (2 KB / 4 KB), same content. 2 KB is native; pick the size your tool asks for.
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is included as well (448 KB).
EDC16C3 0281010390 1037366511 ORI – references
| ECU | Bosch EDC16C3 |
| Bosch hardware (HW) | 0281010390 – printed 0 281 010 390 on the label |
| PSA part number | 9647158180 – printed 96 471 581 80 |
| Software (SW) | 1037366511 – also written SW1037366511 |
| Upgrade / SW upg. | none – your tool shows 1037366511 in both fields, or leaves the second one empty |
| Memory supplied | External flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 533 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC16C3 (fichier d’origine in French, file ori in Italian).
Notes on this file
Hardware 0281010390 is known with 2 software versions in our catalogue; this page is 1037366511. Engine: Peugeot 307 1.4 HDi (68 hp, engine code 8HZ).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C3 you will read 0 281 010 390 (hardware) and 96 471 581 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037366511 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037366511 again |
Your tool should show 1037366511 as SW and either nothing or 1037366511 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281010390: SW 1037351981 (PSA 9646313280) – 307 1.4 HDi
- Other Peugeot 307 EDC16C3 files: 0281011090 · 1037370239 · 0281011234 · 1037370639 upg. 1037372090 · 0281011558 · 1037370763 upg. 1037374181
- Bosch EDC16C3 family: all EDC16C3 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C3 0281010390 1037366511 ORI a full BDM backup or only the flash?
Full backup: the 1 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 307 1.4 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037366511.
My tool shows SW 1037366511 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 390 and 96 471 581 80 on the label; if the upgrade line is empty or repeats 1037366511, this is your file.
Same hardware 0281010390 but my tool shows SW 1037351981?
Then you need the other file for this hardware: SW 1037351981 with PSA 9646313280, sold on its own page. 0281010390 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 307?
Yes, as read. This is the original state of ECU 0281010390, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
