EDC15C2 0281011525 1037368453 ORI is the original full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 206 2.0 HDi (PSA 9651256880): external flash 512 KB + EEPROM 95080 (1 KB), read on the bench and delivered unmodified.
What you get (ZIP, 412 KB)
✔ EDC15C2 0281011525 1037368453 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (412 KB) with the complete memory of a Bosch EDC15C2, read on the bench (Peugeot 206 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 206 | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
| Peugeot 1007 | 2.0 HDi | — | — | reported, not confirmed |
Hardware 0281011525 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281011525 and PSA 9651256880 on the label, then the software number in your tool.
If your 206 shows HW 0281011525 but SW 1037374499 (PSA 9654694380), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011525_9651256880_SW1037368453_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011525_9651256880_SW1037368453_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281011525 1037368453 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011525 – printed 0 281 011 525 on the label |
| PSA part number | 9651256880 – printed 96 512 568 80 |
| Software (SW) | 1037368453 – also written SW1037368453 |
| Upgrade / SW upg. | none – your tool shows 1037368453 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 412 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC15C2 (fichier d’origine in French, file ori in Italian).
Notes on this file
Hardware 0281011525 is known with 2 software versions in our catalogue; this page is 1037368453. Engine: Peugeot 206 2.0 HDi (90 hp, engine code RHY).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC15C2 housing shows the hardware number 0 281 011 525 and the PSA number 96 512 568 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037368453 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037368453 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037368453 again |
Your tool should show 1037368453 as SW and either nothing or 1037368453 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same software 1037368453: base
- Same hardware 0281011525: SW 1037374499 (PSA 9654694380) – 206 2.0 HDi
- Other Peugeot 206 EDC15C2 files: 0281010500 · 1037353319 · 0281010767 · 1037353536 · 0281010594 · 1037353648 · 0281010767 · 1037353735 · 0281001866 · 1037359123
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011525 1037368453 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 206 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037368453.
My tool shows SW 1037368453 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 525 and 96 512 568 80 on the label; if the upgrade line is empty or repeats 1037368453, this is your file.
Will this file work on a Peugeot 1007 2.0 HDi?
Only if the 1007 label reads HW 0281011525 / PSA 9651256880 and the tool shows 1037368453. It is reported with this software but we did not read it from a 1007 ourselves.
Same hardware 0281011525 but my tool shows SW 1037374499?
Then you need the other file for this hardware: SW 1037374499 with PSA 9654694380, sold on its own page. 0281011525 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 206?
Yes, as read. This is the original state of ECU 0281011525, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
