EDC15C7 0281010484 1037363244 ORI – original full BDM backup from a Bosch EDC15C7 fitted to the Citroën Jumper 2.2 HDi (PSA 1329214080): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 355 KB)
✔ EDC15C7 0281010484 1037363244 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (355 KB) with the complete memory of a Bosch EDC15C7, read on the bench (Citroën Jumper 2.2 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Citroën Jumper | 2.2 HDi | confirmed for this software |
| Peugeot Boxer | 2.2 HDi | twin model – same vehicle as the Citroën Jumper, Peugeot badge |
| Citroën Jumper | 3.0 HDi | reported, not confirmed |
| Fiat Ducato | 2.2 JTD | reported, not confirmed |
| Peugeot Boxer | 2.2 D | reported, not confirmed |
| Peugeot Boxer | 2.8 HDi | reported, not confirmed |
Hardware 0281010484 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281010484 and PSA 1329214080 on the label, then the software number in your tool.
If your Jumper shows HW 0281010484 but SW 1037369278 (PSA 9648608580), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010484_1329214080_SW1037363244_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010484_1329214080_SW1037363244_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C7 with the usual tools.
EDC15C7 0281010484 1037363244 ORI – references
| ECU | Bosch EDC15C7 |
| Bosch hardware (HW) | 0281010484 – printed 0 281 010 484 on the label |
| PSA part number | 1329214080 – printed 1329214080 |
| Software (SW) | 1037363244 – also written SW1037363244 |
| Upgrade / SW upg. | none – your tool shows 1037363244 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 355 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Hardware 0281010484 is known with 2 software versions in our catalogue; this page is 1037363244.
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C7. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC15C7 housing shows the hardware number 0 281 010 484 and the PSA number 1329214080; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037363244 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037363244 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037363244 again |
Expected ID screen: SW 1037363244, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same software 1037363244: base
- Same hardware 0281010484: SW 1037369278 (PSA 9648608580) – Jumper 2.2 HDi
- Other Citroën Jumper EDC15C7 files: 0281010486 · 1037360012 · 0281010931 · 1037366765 · 0281010346 · 1037369277 · 0281010345 · 1037369918 · 0281010931 · 1037376531
- Bosch EDC15C7 family: all EDC15C7 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C7 0281010484 1037363244 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Jumper 2.2 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037363244.
My tool shows SW 1037363244 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 484 and 1329214080 on the label; if the upgrade line is empty or repeats 1037363244, this is your file.
Does it fit the Peugeot Boxer 2.2 HDi?
Yes – the Boxer is the twin of the Citroën Jumper: same engine, same EDC15C7. Check 0 281 010 484 and 1329214080 on the label and software 1037363244 in your tool before ordering.
Will this file work on a Citroën Jumper 3.0 HDi?
Only if the Jumper label reads HW 0281010484 / PSA 1329214080 and the tool shows 1037363244. It is reported with this software but we did not read it from a Jumper ourselves.
Same hardware 0281010484 but my tool shows SW 1037369278?
Then you need the other file for this hardware: SW 1037369278 with PSA 9648608580, sold on its own page. 0281010484 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor Jumper?
Yes, as read. This is the original state of ECU 0281010484, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
