EDC15C7 0281010345 1037369918 ORI is the original full BDM backup of a Bosch EDC15C7 fitted to the Citroën Jumper 2.2 HDi (PSA 9648608680): external flash 512 KB + EEPROM 95080 (1 KB), read on the bench and delivered unmodified.
What you get (ZIP, 355 KB)
✔ EDC15C7 0281010345 1037369918 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (355 KB) holding the software of a Bosch EDC15C7 read on the bench (Citroën Jumper 2.2 HDi application): external flash 512 KB + EEPROM 95080 (1 KB) from the same unit, with an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Peugeot Boxer | 2.2 HDi | twin model – same vehicle as the Citroën Jumper, Peugeot badge |
| Citroën Jumper | 2.2 HDi | confirmed for this software |
| Fiat Ducato | 2.2 JTD | reported, not confirmed |
Do not rely on the model alone: check HW 0281010345 and PSA 9648608680 on the label, then 1037369918 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010345_9648608680_SW1037369918_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010345_9648608680_SW1037369918_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C7 with the usual tools.
EDC15C7 0281010345 1037369918 ORI – references
| ECU | Bosch EDC15C7 |
| Bosch hardware (HW) | 0281010345 – printed 0 281 010 345 on the label |
| PSA part number | 9648608680 – printed 96 486 086 80 |
| Software (SW) | 1037369918 – also written SW1037369918 |
| Upgrade / SW upg. | none – your tool shows 1037369918 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 355 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
This page covers one exact software: EDC15C7 0281010345 with SW 1037369918. Another number on your tool means another file – use the search or ask us.
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C7 you will read 0 281 010 345 (hardware) and 96 486 086 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037369918 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037369918 again |
Your tool should show 1037369918 as SW and either nothing or 1037369918 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Other Citroën Jumper EDC15C7 files: 0281010486 · 1037360012 · 0281010484 · 1037363244 · 0281010484 · 1037363244 · 0281010931 · 1037366765 · 0281010346 · 1037369277
- Bosch EDC15C7 family: all EDC15C7 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C7 0281010345 1037369918 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Jumper 2.2 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037369918.
My tool shows SW 1037369918 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 345 and 96 486 086 80 on the label; if the upgrade line is empty or repeats 1037369918, this is your file.
Does it fit the Peugeot Boxer 2.2 HDi?
Yes – the Boxer is the twin of the Citroën Jumper: same engine, same EDC15C7. Check 0 281 010 345 and 96 486 086 80 on the label and software 1037369918 in your tool before ordering.
Will this file work on a Fiat Ducato 2.2 JTD?
Only if the Ducato label reads HW 0281010345 / PSA 9648608680 and the tool shows 1037369918. It is reported with this software but we did not read it from a Ducato ourselves.
Does the EEPROM contain the immobiliser of the donor Jumper?
Yes, as read. This is the original state of ECU 0281010345, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
