What you get (ZIP, 355 KB)
✔ EDC15C7 0281010484 1037363244 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (355 KB) holding the software of a Bosch EDC15C7 read on the bench (Citroën Jumper 2.2 HDi application): external flash 512 KB + EEPROM 95080 (1 KB) from the same unit, with an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Citroën Jumper | 2.2 HDi | confirmed for this software |
| Peugeot Boxer | 2.2 HDi | twin model – same vehicle as the Citroën Jumper, Peugeot badge |
| Citroën Jumper | 3.0 HDi | reported, not confirmed |
| Fiat Ducato | 2.2 HDi | reported, not confirmed |
| Peugeot Boxer | 2.2 D | reported, not confirmed |
| Peugeot Boxer | 2.8 HDi | reported, not confirmed |
Do not rely on the model alone: check HW 0281010484 and PSA 1329214080 on the label, then 1037363244 on the identification screen of your tool.
With HW 0281010484 but PSA 9648608580 / SW 1037369278, take that file.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010484_1329214080_SW1037363244_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010484_1329214080_SW1037363244_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C7 with the usual tools.
EDC15C7 0281010484 1037363244 ORI – references
| ECU | Bosch EDC15C7 |
| Bosch hardware (HW) | 0281010484 – printed 0 281 010 484 on the label |
| PSA part number | 1329214080 – printed 1329214080 |
| Software (SW) | 1037363244 – also written SW1037363244 |
| Upgrade / SW upg. | none – your tool shows 1037363244 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 355 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
Hardware 0281010484 is known with 2 software versions in our catalogue; this page is 1037363244.
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C7. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 010 484 and 1329214080. The 1039S… sticker is not a software number – 1037363244 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037363244 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037363244 again |
Your tool should show 1037363244 as SW and either nothing or 1037363244 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same software 1037363244: base
- Same hardware 0281010484: SW 1037369278 (PSA 9648608580) – Jumper 2.2 HDi
- Other Citroën Jumper EDC15C7 files: 0281010486 · 1037360012 · 0281010346 · 1037369277 · 0281010345 · 1037369918
- Bosch EDC15C7 family: all EDC15C7 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C7 0281010484 1037363244 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Jumper 2.2 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037363244.
My tool shows SW 1037363244 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 484 and 1329214080 on the label; if the upgrade line is empty or repeats 1037363244, this is your file.
Will this file work on a Citroën Jumper 3.0 HDi?
Only if the Jumper label reads HW 0281010484 / PSA 1329214080 and the tool shows 1037363244. It is reported with this software but we did not read it from a Jumper ourselves.
Same hardware 0281010484 but my tool shows SW 1037369278?
Then you need the other file for this hardware: SW 1037369278 with PSA 9648608580, sold on its own page. 0281010484 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor Jumper?
Yes, as read. This is the original state of ECU 0281010484, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
