EDC15C7 0281010929 1037363535 – original full BDM backup from a Bosch EDC15C7 fitted to the Fiat Ducato 2.8 JTD (PSA 1336827080): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (2 ZIPs, 729 KB in total)
✔ EDC15C7 0281010929 1037363535 full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC15C7, read on the bench (Fiat Ducato 2.8 JTD application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. Moreover, the ZIP is delivered instantly once the order is paid.
Two independent reads of the same software, from two different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the other to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Citroën Jumper | 2.8 HDi | 126 hp / 93 kW | twin model – same vehicle as the Fiat Ducato, Citroën badge |
| Fiat Ducato | 2.8 JTD | 126 hp / 93 kW | confirmed for this software |
| Peugeot Boxer | 2.8 HDi | 128 hp / 94 kW | twin model – same vehicle as the Fiat Ducato, Peugeot badge |
Two Ducato with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010929, PSA 1336827080 – and the software 1037363535 shown by your tool before ordering.
Archive contents
Read #1 – 0281010929_1336827080_SW1037363535_N1.zip (357 KB)
| File | Memory | Size |
|---|---|---|
0281010929_1336827080_SW1037363535_N1_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010929_1336827080_SW1037363535_N1_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281010929_1336827080_SW1037363535_N2.zip (372 KB)
| File | Memory | Size |
|---|---|---|
0281010929_1336827080_SW1037363535_N2_FLASH.bin | External flash | 524 288 bytes (512 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 17 bytes differ in the flash (5 areas: 0x07F15D–0x07F166, 0x07F16B–0x07F16C, 0x07F176, …).
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C7 with the usual tools.
EDC15C7 0281010929 1037363535 – references
| ECU | Bosch EDC15C7 |
| Bosch hardware (HW) | 0281010929 – printed 0 281 010 929 on the label |
| PSA part number | 1336827080 – printed 1336827080 |
| Software (SW) | 1037363535 – also written SW1037363535 |
| Upgrade / SW upg. | none – your tool shows 1037363535 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 729 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
We read two EDC15C7 ECUs running software 1037363535 for this page. Engine: Fiat Ducato 2.8 JTD (126 hp).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C7 you will read 0 281 010 929 (hardware) and 1336827080 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037363535 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037363535 again |
Your tool should show 1037363535 as SW and either nothing or 1037363535 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Other Fiat Ducato EDC15C7 files: 0281010486 · 1037360012 · 0281010931 · 1037366765 · 0281010346 · 1037369277 · 0281010931 · 1037376531
- Bosch EDC15C7 family: all EDC15C7 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C7 0281010929 1037363535 a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Fiat Ducato 2.8 JTD application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037363535.
My tool shows SW 1037363535 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 929 and 1336827080 on the label; if the upgrade line is empty or repeats 1037363535, this is your file.
Does it fit the Citroën Jumper 2.8 HDi?
Yes – the Jumper is the twin of the Fiat Ducato: same engine, same EDC15C7. Check 0 281 010 929 and 1336827080 on the label and software 1037363535 in your tool before ordering.
Does it fit the Peugeot Boxer 2.8 HDi?
Yes – the Boxer is the twin of the Fiat Ducato: same engine, same EDC15C7. Check 0 281 010 929 and 1336827080 on the label and software 1037363535 in your tool before ordering.
Why are there 2 downloads for one software?
We read 2 ECUs running 1037363535. Write read #1; the other differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor Ducato?
Yes, as read. This is the original state of ECU 0281010929, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
