EDC15C7 0281010931 1037376531 – original full BDM backup from a Bosch EDC15C7 fitted to the Citroën Jumper 2.8 HDi (PSA 1351212080): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 359 KB)
✔ EDC15C7 0281010931 1037376531 full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (359 KB) holding the software of a Bosch EDC15C7 read on the bench (Citroën Jumper 2.8 HDi application): external flash 512 KB + EEPROM 95080 (1 KB) from the same unit, with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën Jumper | 2.8 HDi | — | — | confirmed for this software |
| Fiat Ducato | 2.8 JTD | — | 127 hp / 93 kW | twin model – same vehicle as the Citroën Jumper, Fiat badge |
| Peugeot Boxer | 2.8 HDi | 8HDI | 128 hp / 94 kW | twin model – same vehicle as the Citroën Jumper, Peugeot badge |
Do not rely on the model alone: check HW 0281010931 and PSA 1351212080 on the label, then 1037376531 on the identification screen of your tool.
Same hardware 0281010931, different software 1037366765? That one is sold separately here.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010931_1351212080_SW1037376531_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010931_1351212080_SW1037376531_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C7 with the usual tools.
EDC15C7 0281010931 1037376531 – references
| ECU | Bosch EDC15C7 |
| Bosch hardware (HW) | 0281010931 – printed 0 281 010 931 on the label |
| PSA part number | 1351212080 – printed 1351212080 |
| Software (SW) | 1037376531 – also written SW1037376531 |
| Upgrade / SW upg. | none – your tool shows 1037376531 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 359 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC15C7 (fichier d’origine in French, file ori in Italian).
Notes on this file
Hardware 0281010931 is known with 2 software versions in our catalogue; this page is 1037376531.
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 010 931 and 1351212080. The 1039S… sticker is not a software number – 1037376531 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037376531 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037376531 again |
Expected ID screen: SW 1037376531, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281010931: SW 1037366765 (PSA 1337648080) – Jumper 2.8 HDi
- Other Citroën Jumper EDC15C7 files: 0281010486 · 1037360012 · 0281010484 · 1037363244 · 0281010484 · 1037363244 · 0281010346 · 1037369277 · 0281010484 · 1037369278
- Bosch EDC15C7 family: all EDC15C7 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C7 0281010931 1037376531 a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Jumper 2.8 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037376531.
My tool shows SW 1037376531 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 931 and 1351212080 on the label; if the upgrade line is empty or repeats 1037376531, this is your file.
Does it fit the Fiat Ducato 2.8 JTD?
Yes – the Ducato is the twin of the Citroën Jumper: same engine, same EDC15C7. Check 0 281 010 931 and 1351212080 on the label and software 1037376531 in your tool before ordering.
Does it fit the Peugeot Boxer 2.8 HDi?
Yes – the Boxer is the twin of the Citroën Jumper: same engine, same EDC15C7. Check 0 281 010 931 and 1351212080 on the label and software 1037376531 in your tool before ordering.
Same hardware 0281010931 but my tool shows SW 1037366765?
Then you need the other file for this hardware: SW 1037366765 with PSA 1337648080, sold on its own page. 0281010931 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor Jumper?
Yes, as read. This is the original state of ECU 0281010931, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
