EDC16C34 0281013332 1037383737 1037386141: the unmodified full BDM backup of a Bosch EDC16C34 fitted to the Citroën C4 1.6 HDi (PSA 9664257580) – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) read on the bench.
What you get (9 ZIPs, 6.6 MB in total)
✔ EDC16C34 0281013332 1037383737 1037386141 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC16C34, read on the bench (Citroën C4 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
Also, the download opens as soon as the payment is confirmed.
9 independent reads of the same software, from 9 different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Citroën C4 | 1.6 HDi | 9HZ | 110 hp / 80 kW | — | confirmed for this software |
| Peugeot 307 | 1.6 HDi | 9HZ | 110 hp / 80 kW | — | confirmed for this software |
| Peugeot 407 | 1.6 HDi | 9HZ | 110 hp / 80 kW | — | confirmed for this software |
| Peugeot 307 | 1.6 DIESEL | — | — | 2001-2008 | reported, not confirmed |
| Peugeot 308 | 1.6 HDi | — | — | — | reported, not confirmed |
Two C4 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281013332, PSA 9664257580 – and the software 1037383737 shown by your tool before ordering.
With HW 0281013332 but PSA 9662213180 / SW 1037380086, take that file.
Archive contents
9 separate reads of the same EDC16C34 software 1037383737, each from another car: one ZIP per read. The table shows how many bytes differ from read #1.
| Read | ZIP | Size | Differences from read #1 |
|---|---|---|---|
| Read #1 | 0281013332_9664257580_SW1037383737_MJ1037386141_N1.zip | 737 KB | reference read |
| Read #2 | 0281013332_9664257580_SW1037383737_MJ1037386141_N2.zip | 753 KB | 20 bytes differ in the flash; 435 bytes differ in the EEPROM |
| Read #3 | 0281013332_9664257580_SW1037383737_MJ1037386141_N3.zip | 752 KB | 20 bytes differ in the flash; 404 bytes differ in the EEPROM |
| Read #4 | 0281013332_9664257580_SW1037383737_MJ1037386141_N4.zip | 753 KB | 20 bytes differ in the flash; 367 bytes differ in the EEPROM |
| Read #5 | 0281013332_9664257580_SW1037383737_MJ1037386141_N5.zip | 753 KB | 16 bytes differ in the flash; 414 bytes differ in the EEPROM |
| Read #6 | 0281013332_9664257580_SW1037383737_MJ1037386141_N6.zip | 753 KB | 20 bytes differ in the flash; 548 bytes differ in the EEPROM |
| Read #7 | 0281013332_9664257580_SW1037383737_MJ1037386141_N7.zip | 753 KB | 16 bytes differ in the flash; 455 bytes differ in the EEPROM |
| Read #8 | 0281013332_9664257580_SW1037383737_MJ1037386141_N8.zip | 753 KB | 20 bytes differ in the flash; 508 bytes differ in the EEPROM |
| Read #9 | 0281013332_9664257580_SW1037383737_MJ1037386141_N9.zip | 753 KB | 20 bytes differ in the flash; 455 bytes differ in the EEPROM |
Files in each ZIP (read #1 shown)
| File | Memory | Size |
|---|---|---|
0281013332_9664257580_SW1037383737_MJ1037386141_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013332_9664257580_SW1037383737_MJ1037386141_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013332_9664257580_SW1037383737_MJ1037386141_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013332_9664257580_SW1037383737_MJ1037386141_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
EDC16C34 0281013332 1037383737 1037386141 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281013332 – printed 0 281 013 332 on the label |
| PSA part number | 9664257580 – printed 96 642 575 80 |
| Software (SW) | 1037383737 – also written SW1037383737 |
| Upgrade / SW upg. | 1037386141 – also written MJ1037386141; your tool shows SW 1037383737 and SW upg. 1037386141 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 6.6 MB, instant download after payment |
Notes on this file
We read 9 EDC16C34 ECUs running software 1037383737 for this page. Hardware 0281013332 is known with 4 software versions in our catalogue; this page is 1037383737 updated to 1037386141. Engine: Citroën C4 1.6 HDi (110 hp, engine code 9HZ).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 013 332 and 96 642 575 80. The 1039S… sticker is not a software number – 1037383737 is only visible through a tool or in INFOS.html.

What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037383737 |
| SW upg. (SW màj., soft up, UpgSW) | 1037386141 |
Two numbers = this file: SW 1037383737 and SW upg. 1037386141. One number 1037386141 alone = still this file. 1037383737 twice = the factory read, sold on its own page.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037386141 | SW 1037383737 / SW upg. 1037386141 | C4 1.6 HDi | this file |
| upgrade 1037386118 | SW 1037383737 / SW upg. 1037386118 | C4 1.6 HDi | open |
| upgrade 1037386129 | SW 1037383737 / SW upg. 1037386129 | C4 1.6 HDi | open |
| upgrade 1037386135 | SW 1037383737 / SW upg. 1037386135 | C4 1.6 HDi | open |
| upgrade 1037386144 | SW 1037383737 / SW upg. 1037386144 | C4 1.6 HDi | open |
| upgrade 1037389505 | SW 1037383737 / SW upg. 1037389505 | C4 1.6 HDi | open |
- Same hardware 0281013332: SW 1037380086 (PSA 9662213180) – C4 1.6 HDi · SW 1037381893 (PSA 9664257580) – C4 1.6 HDi · SW 1037386166 (PSA 9664843780) – 308 1.6 HDi
- Other Citroën C4 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011630 · 1037372085 upg. 1037380728 · 0281011629 · 1037374179
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281013332 1037383737 1037386141 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C4 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037383737.
My tool shows SW 1037383737 and SW upg. 1037386141 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037386141, and 1037383737 is the base number the ECU still reports.
My tool shows only “SW upg. 1037386141” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281013332 and 9664257580 on the label and you are good.
Does it fit the Peugeot 307 1.6 HDi?
Yes – the 307 is confirmed for this software. Check 0 281 013 332 and 96 642 575 80 on the label and software 1037383737 in your tool before ordering.
Does it fit the Peugeot 407 1.6 HDi?
Yes – the 407 is confirmed for this software. Check 0 281 013 332 and 96 642 575 80 on the label and software 1037383737 in your tool before ordering.
Will this file work on a Peugeot 307 1.6 DIESEL?
Only if the 307 label reads HW 0281013332 / PSA 9664257580 and the tool shows 1037383737 / 1037386141. It is reported with this software but we did not read it from a 307 ourselves.
