EDC16C34 0281013868 1037380749 1037501007 is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 207 1.6 HDi (PSA 9663755480): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 755 KB)
✔ EDC16C34 0281013868 1037380749 1037501007 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (755 KB) holding the updated software of a Bosch EDC16C34 read on the bench (Peugeot 207 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 207 | 1.6 HDi | 9HX | 90 hp / 66 kW | confirmed for this software |
Two 207 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281013868, PSA 9663755480 – and the software 1037380749 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281013868_9663755480_SW1037380749_MJ1037501007_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013868_9663755480_SW1037380749_MJ1037501007_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013868_9663755480_SW1037380749_MJ1037501007_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013868_9663755480_SW1037380749_MJ1037501007_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
EDC16C34 0281013868 1037380749 1037501007 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281013868 – printed 0 281 013 868 on the label |
| PSA part number | 9663755480 – printed 96 637 554 80 |
| Software (SW) | 1037380749 – also written SW1037380749 |
| Upgrade / SW upg. | 1037501007 – also written MJ1037501007; your tool shows SW 1037380749 and SW upg. 1037501007 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 755 KB, instant download after payment |
Notes on this file
Engine: Peugeot 207 1.6 HDi (90 hp, engine code 9HX).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 013 868 and 96 637 554 80. The 1039S… sticker is not a software number – 1037380749 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037380749 |
| SW upg. (SW màj., soft up, UpgSW) | 1037501007 |
Look for the pair 1037380749 / 1037501007 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1037501007 alone, points to this file; 1037380749 twice points to the non-updated read.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037501007 | SW 1037380749 / SW upg. 1037501007 | 207 1.6 HDi | this file |
| upgrade 1037386111 | SW 1037380749 / SW upg. 1037386111 | 207 1.6 HDi | open |
| upgrade 1037386112 | SW 1037380749 / SW upg. 1037386112 | 207 1.6 HDi | open |
| upgrade 1037386113 | SW 1037380749 / SW upg. 1037386113 | 207 1.6 HDi | open |
| upgrade 1037386119 | SW 1037380749 / SW upg. 1037386119 | 207 1.6 HDi | open |
| upgrade 1037389529 | SW 1037380749 / SW upg. 1037389529 | 207 1.6 HDi | open |
- Other Peugeot 207 EDC16C34 files: 0281012465 · 1037375963 · 0281012529 · 1037379216 upg. 1037380738 · 0281012985 · 1037379394 upg. 1037386114 · 0281012985 · 1037379394 upg. 1037386115 · 0281012985 · 1037379394 upg. 1039398213
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281013868 1037380749 1037501007 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 207 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037380749.
My tool shows SW 1037380749 and SW upg. 1037501007 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037501007, and 1037380749 is the base number the ECU still reports.
My tool shows only “SW upg. 1037501007” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281013868 and 9663755480 on the label and you are good.
Will this file work on a Peugeot 307?
Only if the 307 label reads HW 0281013868 / PSA 9663755480 and the tool shows 1037380749 / 1037501007. It is reported with this software but we did not read it from a 307 ourselves.
