EDC16C34 0281013872 1037386166 1037398248 – original full BDM backup from a Bosch EDC16C34 fitted to the Peugeot 308 1.6 HDi (PSA 9664843780): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (ZIP, 753 KB)
✔ EDC16C34 0281013872 1037386166 1037398248 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (753 KB) holding the updated software of a Bosch EDC16C34 read on the bench (Peugeot 308 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Peugeot 308 | 1.6 HDi | 9HT | 110 hp / 80 kW | — | confirmed for this software |
| Citroën Berlingo | 1.6 HDi | 9HV | 75 hp / 55 kW | — | reported, not confirmed |
| Citroën C4 | 1.6 HDi | 9HY | — | 2004-2010 | reported, not confirmed |
| Peugeot 207 | 1.4 HDi | — | — | — | reported, not confirmed |
| Peugeot 207 | 1.6 HDi | — | 110 hp / 80 kW | — | reported, not confirmed |
| Peugeot 307 | 1.6 HDi | — | 110 hp / 80 kW | — | reported, not confirmed |
| Peugeot 407 | 1.6 HDi | — | — | — | reported, not confirmed |
| Peugeot Partner | 1.6 HDi | 9HV | 75 hp / 55 kW | — | reported, not confirmed |
Do not rely on the model alone: check HW 0281013872 and PSA 9664843780 on the label, then 1037386166 and 1037398248 on the identification screen of your tool.
Same hardware 0281013872, different software 1039398220? That one is sold separately here.
Archive contents
| File | Memory | Size |
|---|---|---|
0281013872_9664843780_SW1037386166_MJ1037398248_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013872_9664843780_SW1037386166_MJ1037398248_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013872_9664843780_SW1037386166_MJ1037398248_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013872_9664843780_SW1037386166_MJ1037398248_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
EDC16C34 0281013872 1037386166 1037398248 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281013872 – printed 0 281 013 872 on the label |
| PSA part number | 9664843780 – printed 96 648 437 80 |
| Software (SW) | 1037386166 – also written SW1037386166 |
| Upgrade / SW upg. | 1037398248 – also written MJ1037398248; your tool shows SW 1037386166 and SW upg. 1037398248 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 753 KB, instant download after payment |
Notes on this file
Hardware 0281013872 is known with 2 software versions in our catalogue; this page is 1037386166 updated to 1037398248. Engine: Peugeot 308 1.6 HDi (110 hp, engine code 9HT).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 013 872 and the PSA number 96 648 437 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037386166 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037386166 |
| SW upg. (SW màj., soft up, UpgSW) | 1037398248 |
Look for the pair 1037386166 / 1037398248 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1037398248 alone, points to this file; 1037386166 twice points to the non-updated read.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037398248 | SW 1037386166 / SW upg. 1037398248 | 308 1.6 HDi | this file |
| upgrade 1037389534 | SW 1037386166 / SW upg. 1037389534 | 308 1.6 HDi | open |
| upgrade 1037389540 | SW 1037386166 / SW upg. 1037389540 | 308 1.6 HDi | open |
| upgrade 1037389545 | SW 1037386166 / SW upg. 1037389545 | 308 1.6 HDi | open |
| upgrade 1037389546 | SW 1037386166 / SW upg. 1037389546 | 308 1.6 HDi | open |
| upgrade 1037389547 | SW 1037386166 / SW upg. 1037389547 | 308 1.6 HDi | open |
- Same hardware 0281013872: SW 1039398220 (PSA 9664843780) – 308 1.6 HDi
- Other Peugeot 308 EDC16C34 files: 0281013871 · 1037383745 upg. 1037389514 · 0281011629 · 1037386166 upg. 1037395378 · 0281012985 · 1037386166 upg. 1039398234 · 0281013871 · 1037386178 upg. 1037389514 · 0281013871 · 1037386178 upg. 1037393468
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281013872 1037386166 1037398248 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 308 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037386166.
My tool shows SW 1037386166 and SW upg. 1037398248 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037398248, and 1037386166 is the base number the ECU still reports.
My tool shows only “SW upg. 1037398248” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281013872 and 9664843780 on the label and you are good.
Will this file work on a Citroën Berlingo 1.6 HDi?
Only if the Berlingo label reads HW 0281013872 / PSA 9664843780 and the tool shows 1037386166 / 1037398248. It is reported with this software but we did not read it from a Berlingo ourselves.
