EDC16C34 0281012625 1037375958 ORI: the unmodified full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 407 1.6 HDi (PSA 9661005580) – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) read on the bench.
What you get (ZIP, 654 KB)
✔ EDC16C34 0281012625 1037375958 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (654 KB) holding the software of a Bosch EDC16C34 read on the bench (Peugeot 407 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Peugeot 407 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
| Peugeot 407 | 1.6 HDİ | — | reported, not confirmed |
Two 407 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281012625, PSA 9661005580 – and the software 1037375958 shown by your tool before ordering.
With HW 0281012625 but PSA 9659728280 / SW 1037375518, take that file.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012625_9661005580_SW1037375958_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012625_9661005580_SW1037375958_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012625_9661005580_SW1037375958_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012625_9661005580_SW1037375958_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
The EEPROM is supplied in three formats for multi-tool compatibility – 2 KB / 4 KB / 8 KB – with the same data: 2 KB is the chip’s native size, the larger ones suit tools that expect a bigger file. Load the one your tool accepts.
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281012625 1037375958 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012625 – printed 0 281 012 625 on the label |
| PSA part number | 9661005580 – printed 96 610 055 80 |
| Software (SW) | 1037375958 – also written SW1037375958 |
| Upgrade / SW upg. | none – your tool shows 1037375958 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 654 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Hardware 0281012625 is known with 2 software versions in our catalogue; this page is 1037375958. Engine: Peugeot 407 1.6 HDi (110 hp).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 012 625 and the PSA number 96 610 055 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037375958 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037375958 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037375958 again |
Expected ID screen: SW 1037375958, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281012625: SW 1037375518 (PSA 9659728280) – 407 1.6 HDi
- Other Peugeot 407 EDC16C34 files: 0281011633 · 1037374956 upg. 1037375532 · 0281011633 · 1037374956 upg. 1037377754 · 0281012984 · 1037380721 · 0281013332 · 1037383737 upg. 1037386118 · 0281013332 · 1037383737 upg. 1037386135
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012625 1037375958 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 407 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037375958.
My tool shows SW 1037375958 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 012 625 and 96 610 055 80 on the label; if the upgrade line is empty or repeats 1037375958, this is your file.
Will this file work on a Peugeot 407 1.6 HDİ?
Only if the 407 label reads HW 0281012625 / PSA 9661005580 and the tool shows 1037375958. It is reported with this software but we did not read it from a 407 ourselves.
Same hardware 0281012625 but my tool shows SW 1037375518?
Then you need the other file for this hardware: SW 1037375518 with PSA 9659728280, sold on its own page. 0281012625 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 407?
Yes, as read. This is the original state of ECU 0281012625, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
