EDC16C34 0281012625 1037375518 ORI – original full BDM backup from a Bosch EDC16C34 fitted to the Peugeot 407 1.6 HDi (PSA 9659728280): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), bench read, nothing modified.
What you get (ZIP, 649 KB)
✔ EDC16C34 0281012625 1037375518 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Peugeot 407 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Peugeot 407 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
Hardware 0281012625 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281012625 and PSA 9659728280 on the label, then the software number in your tool.
If your 407 shows HW 0281012625 but SW 1037375958 (PSA 9661005580), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012625_9659728280_SW1037375518_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012625_9659728280_SW1037375518_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012625_9659728280_SW1037375518_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012625_9659728280_SW1037375518_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281012625 1037375518 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012625 – printed 0 281 012 625 on the label |
| PSA part number | 9659728280 – printed 96 597 282 80 |
| Software (SW) | 1037375518 – also written SW1037375518 |
| Upgrade / SW upg. | none – your tool shows 1037375518 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 649 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Hardware 0281012625 is known with 2 software versions in our catalogue; this page is 1037375518. Engine: Peugeot 407 1.6 HDi (110 hp).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 012 625 and 96 597 282 80. The 1039S… sticker is not a software number – 1037375518 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037375518 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037375518 again |
Expected ID screen: SW 1037375518, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281012625: SW 1037375958 (PSA 9661005580) – 407 1.6 HDi
- Other Peugeot 407 EDC16C34 files: 0281011633 · 1037374956 upg. 1037375532 · 0281011633 · 1037374956 upg. 1037377754 · 0281012984 · 1037380721 · 0281013332 · 1037383737 upg. 1037386118 · 0281013332 · 1037383737 upg. 1037386135
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012625 1037375518 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 407 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037375518.
My tool shows SW 1037375518 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 012 625 and 96 597 282 80 on the label; if the upgrade line is empty or repeats 1037375518, this is your file.
Same hardware 0281012625 but my tool shows SW 1037375958?
Then you need the other file for this hardware: SW 1037375958 with PSA 9661005580, sold on its own page. 0281012625 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 407?
Yes, as read. This is the original state of ECU 0281012625, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
