EDC15C2 0281011341 1037371045 ORI is the original full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 307 2.0 HDi (PSA 9653873280): external flash 512 KB + EEPROM 95080 (1 KB), read on the bench and delivered unmodified.
What you get (2 ZIPs, 840 KB in total)
✔ EDC15C2 0281011341 1037371045 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC15C2, read on the bench (Peugeot 307 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. In addition, the download link is available right after payment.
Two independent reads of the same software, from two different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the other to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 307 | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
Two 307 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011341, PSA 9653873280 – and the software 1037371045 shown by your tool before ordering.
Archive contents
Read #1 – 0281011341_9653873280_SW1037371045_N1.zip (412 KB)
| File | Memory | Size |
|---|---|---|
0281011341_9653873280_SW1037371045_N1_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011341_9653873280_SW1037371045_N1_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011341_9653873280_SW1037371045_N2.zip (427 KB)
| File | Memory | Size |
|---|---|---|
0281011341_9653873280_SW1037371045_N2_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011341_9653873280_SW1037371045_N2_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 4 bytes differ in the flash (2 areas: 0x07EC12–0x07EC13, 0x07EC3A–0x07EC3B); 115 bytes differ in the EEPROM (28 areas: 0x000000–0x000004, 0x000009, 0x00000B–0x00000C, …).
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281011341 1037371045 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011341 – printed 0 281 011 341 on the label |
| PSA part number | 9653873280 – printed 96 538 732 80 |
| Software (SW) | 1037371045 – also written SW1037371045 |
| Upgrade / SW upg. | none – your tool shows 1037371045 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 840 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
We read two EDC15C2 ECUs running software 1037371045 for this page. Engine: Peugeot 307 2.0 HDi (90 hp, engine code RHY).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 011 341 and 96 538 732 80. The 1039S… sticker is not a software number – 1037371045 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037371045 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037371045 again |
Expected ID screen: SW 1037371045, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011341 1037371045 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 307 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037371045.
My tool shows SW 1037371045 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 341 and 96 538 732 80 on the label; if the upgrade line is empty or repeats 1037371045, this is your file.
Why are there 2 downloads for one software?
We read 2 ECUs running 1037371045. Write read #1; the other differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor 307?
Yes, as read. This is the original state of ECU 0281011341, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
