EDC15C2 0281011340 1037364447 ORI – original full BDM backup from a Bosch EDC15C2 fitted to the Citroën C5 2.0 HDi (PSA 9649158380): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 410 KB)
✔ EDC15C2 0281011340 1037364447 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (410 KB) holding the software of a Bosch EDC15C2 read on the bench (Citroën C5 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB) from the same unit, with an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Citroën C5 | 2.0 HDi | RHZ | 110 hp / 80 kW | 2001-2004 | confirmed for this software |
| Citroën C5 | — | — | 110 hp / 81 kW | — | confirmed for this software |
Hardware 0281011340 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281011340 and PSA 9649158380 on the label, then the software number in your tool.
Same hardware 0281011340, different software 1037368212? That one is sold separately here.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011340_9649158380_SW1037364447_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011340_9649158380_SW1037364447_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281011340 1037364447 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011340 – printed 0 281 011 340 on the label |
| PSA part number | 9649158380 – printed 96 491 583 80 |
| Software (SW) | 1037364447 – also written SW1037364447 |
| Upgrade / SW upg. | none – your tool shows 1037364447 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 410 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
Hardware 0281011340 is known with 2 software versions in our catalogue; this page is 1037364447. Engine: Citroën C5 2.0 HDi (110 hp, engine code RHZ, 2001-2004).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC15C2 housing shows the hardware number 0 281 011 340 and the PSA number 96 491 583 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037364447 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037364447 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037364447 again |
Your tool should show 1037364447 as SW and either nothing or 1037364447 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281011340: SW 1037368212 (PSA 9652386080) – C5 2.0 HDi
- Other Citroën C5 EDC15C2 files: 0281010365 · 1037353324 · 0281010641 · 1037353491 · 0281010764 · 1037353572 · 0281010808 · 1037353613 · 0281010886 · 1037353785
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011340 1037364447 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën C5 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037364447.
My tool shows SW 1037364447 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 340 and 96 491 583 80 on the label; if the upgrade line is empty or repeats 1037364447, this is your file.
Same hardware 0281011340 but my tool shows SW 1037368212?
Then you need the other file for this hardware: SW 1037368212 with PSA 9652386080, sold on its own page. 0281011340 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor C5?
Yes, as read. This is the original state of ECU 0281011340, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
