EDC15C2 0281011340 1037368212 ORI – original full BDM backup from a Bosch EDC15C2 fitted to the Citroën C5 2.0 HDi (PSA 9652386080): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 408 KB)
✔ EDC15C2 0281011340 1037368212 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC15C2 used in the Citroën C5 2.0 HDi: external flash 512 KB + EEPROM 95080 (1 KB) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Citroën C5 | 2.0 HDi | RHZ | 110 hp / 80 kW | 2001-2004 | confirmed for this software |
| Peugeot 406 | 2.0 HDi | RHZ | 110 hp / 80 kW | — | reported, not confirmed |
Two C5 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011340, PSA 9652386080 – and the software 1037368212 shown by your tool before ordering.
If your C5 shows HW 0281011340 but SW 1037364447 (PSA 9649158380), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011340_9652386080_SW1037368212_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011340_9652386080_SW1037368212_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281011340 1037368212 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011340 – printed 0 281 011 340 on the label |
| PSA part number | 9652386080 – printed 96 523 860 80 |
| Software (SW) | 1037368212 – also written SW1037368212 |
| Upgrade / SW upg. | none – your tool shows 1037368212 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 408 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Hardware 0281011340 is known with 2 software versions in our catalogue; this page is 1037368212. Engine: Citroën C5 2.0 HDi (110 hp, engine code RHZ, 2001-2004).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C2. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC15C2 housing shows the hardware number 0 281 011 340 and the PSA number 96 523 860 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037368212 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037368212 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037368212 again |
Your tool should show 1037368212 as SW and either nothing or 1037368212 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281011340: SW 1037364447 (PSA 9649158380) – C5 2.0 HDi
- Other Citroën C5 EDC15C2 files: 0281010365 · 1037353324 · 0281010641 · 1037353491 · 0281010764 · 1037353572 · 0281010808 · 1037353613 · 0281010886 · 1037353785
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011340 1037368212 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën C5 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037368212.
My tool shows SW 1037368212 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 340 and 96 523 860 80 on the label; if the upgrade line is empty or repeats 1037368212, this is your file.
Will this file work on a Peugeot 406 2.0 HDi?
Only if the 406 label reads HW 0281011340 / PSA 9652386080 and the tool shows 1037368212. It is reported with this software but we did not read it from a 406 ourselves.
Same hardware 0281011340 but my tool shows SW 1037364447?
Then you need the other file for this hardware: SW 1037364447 with PSA 9649158380, sold on its own page. 0281011340 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor C5?
Yes, as read. This is the original state of ECU 0281011340, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
