EDC15C2 0281011800 1037372014 1037383360 – original full BDM backup from a Bosch EDC15C2 fitted to the Citroën C5 2.0 HDi (PSA 9656314280): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 414 KB)
✔ EDC15C2 0281011800 1037372014 1037383360 full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (414 KB) with the complete memory of a Bosch EDC15C2, read on the bench (Citroën C5 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Fiat Ulysse | 2.0 JTD | twin model – same vehicle as the Citroën C8, Fiat badge |
| Citroën C5 | 2.0 HDi | confirmed for this software |
| Citroën C8 | 2.0 HDi | confirmed for this software |
| Peugeot 807 | 2.0 HDi | twin model – same vehicle as the Citroën C8, Peugeot badge |
| Lancia Phedra | 2.0 JTD | twin model – same vehicle as the Citroën C8, Lancia badge |
Do not rely on the model alone: check HW 0281011800 and PSA 9656314280 on the label, then 1037372014 and 1037383360 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011800_9656314280_SW1037372014_MJ1037383360_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011800_9656314280_SW1037372014_MJ1037383360_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
EDC15C2 0281011800 1037372014 1037383360 – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011800 – printed 0 281 011 800 on the label |
| PSA part number | 9656314280 – printed 96 563 142 80 |
| Software (SW) | 1037372014 – also written SW1037372014 |
| Upgrade / SW upg. | 1037383360 – also written MJ1037383360; your tool shows SW 1037372014 and SW upg. 1037383360 |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 414 KB, instant download after payment |
Notes on this file
This page covers one exact software: EDC15C2 0281011800 with SW 1037372014 / SW upg. 1037383360. Another number on your tool means another file – use the search or ask us.
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C2 you will read 0 281 011 800 (hardware) and 96 563 142 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037372014 |
| SW upg. (SW màj., soft up, UpgSW) | 1037383360 |
Look for the pair 1037372014 / 1037383360 on the identification screen (SW and SW upg., or SW màj., soft up, UpgSW). The pair, or 1037383360 alone, points to this file; 1037372014 twice points to the non-updated read.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011800 1037372014 1037383360 a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën C5 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037372014.
My tool shows SW 1037372014 and SW upg. 1037383360 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037383360, and 1037372014 is the base number the ECU still reports.
My tool shows only “SW upg. 1037383360” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC15C2. Confirm 0281011800 and 9656314280 on the label and you are good.
Does it fit the Fiat Ulysse 2.0 JTD?
Yes – the Ulysse is the twin of the Citroën C8: same engine, same EDC15C2. Check 0 281 011 800 and 96 563 142 80 on the label and software 1037372014 in your tool before ordering.
Does it fit the Citroën C8 2.0 HDi?
Yes – the C8 is confirmed for this software. Check 0 281 011 800 and 96 563 142 80 on the label and software 1037372014 in your tool before ordering.
Does the EEPROM contain the immobiliser of the donor C5?
Yes, as read. This is the original state of ECU 0281011800, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
