EDC15C2 0281011081 1037364193 ORI: the unmodified full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 307 2.0 HDi (PSA 9647472780) – external flash 512 KB + EEPROM 95080 (1 KB) read on the bench.
What you get (4 ZIPs, 1.6 MB in total)
✔ EDC15C2 0281011081 1037364193 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive holding the software of a Bosch EDC15C2 read on the bench (Peugeot 307 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB) from the same unit, with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Also, the download opens as soon as the payment is confirmed.
Four independent reads of the same software, from four different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 307 | 2.0 HDi | RHZ | 110 hp / 80 kW | confirmed for this software |
Do not rely on the model alone: check HW 0281011081 and PSA 9647472780 on the label, then 1037364193 on the identification screen of your tool.
Archive contents
Read #1 – 0281011081_9647472780_SW1037364193_N1.zip (404 KB)
| File | Memory | Size |
|---|---|---|
0281011081_9647472780_SW1037364193_N1_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011081_9647472780_SW1037364193_N1_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011081_9647472780_SW1037364193_N2.zip (419 KB)
| File | Memory | Size |
|---|---|---|
0281011081_9647472780_SW1037364193_N2_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011081_9647472780_SW1037364193_N2_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281011081_9647472780_SW1037364193_N3.zip (419 KB)
| File | Memory | Size |
|---|---|---|
0281011081_9647472780_SW1037364193_N3_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011081_9647472780_SW1037364193_N3_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #4 – 0281011081_9647472780_SW1037364193_N4.zip (419 KB)
| File | Memory | Size |
|---|---|---|
0281011081_9647472780_SW1037364193_N4_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011081_9647472780_SW1037364193_N4_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 5 bytes differ in the flash (2 areas: 0x07EC12–0x07EC14, 0x07EC3A–0x07EC3B); 265 bytes differ in the EEPROM (50 areas: 0x000007–0x000009, 0x00000B–0x00000C, 0x00000F, …).
Read #3 compared with read #1: 5 bytes differ in the flash (2 areas: 0x07EC12–0x07EC14, 0x07EC3A–0x07EC3B); 252 bytes differ in the EEPROM (46 areas: 0x000007–0x000009, 0x00000F, 0x000012–0x000014, …).
Read #4 compared with read #1: 4 bytes differ in the flash (2 areas: 0x07EC12–0x07EC13, 0x07EC3A–0x07EC3B); 262 bytes differ in the EEPROM (39 areas: 0x000008–0x000009, 0x00000B–0x00000C, 0x00000F, …).
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281011081 1037364193 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011081 – printed 0 281 011 081 on the label |
| PSA part number | 9647472780 – printed 96 474 727 80 |
| Software (SW) | 1037364193 – also written SW1037364193 |
| Upgrade / SW upg. | none – your tool shows 1037364193 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 1.6 MB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
We read four EDC15C2 ECUs running software 1037364193 for this page. Engine: Peugeot 307 2.0 HDi (110 hp, engine code RHZ).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC15C2 housing shows the hardware number 0 281 011 081 and the PSA number 96 474 727 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037364193 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037364193 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037364193 again |
Expected ID screen: SW 1037364193, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011081 1037364193 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 307 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037364193.
My tool shows SW 1037364193 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 081 and 96 474 727 80 on the label; if the upgrade line is empty or repeats 1037364193, this is your file.
Why are there 4 downloads for one software?
We read 4 ECUs running 1037364193. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor 307?
Yes, as read. This is the original state of ECU 0281011081, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
