EDC16C34 0281011627 1037369860 ORI is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 307 1.6 HDi (PSA 9651128880): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (3 ZIPs, 2 MB in total)
✔ EDC16C34 0281011627 1037369860 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC16C34, read on the bench (Peugeot 307 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. Moreover, the ZIP is delivered instantly once the order is paid.
Three independent reads of the same software, from three different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Peugeot 307 | 1.6 HDi | 110 hp / 80 kW | confirmed for this software |
Two 307 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011627, PSA 9651128880 – and the software 1037369860 shown by your tool before ordering.
With HW 0281011627 but PSA 9656161880 / SW 1037371081, take that file.
Archive contents
Read #1 – 0281011627_9651128880_SW1037369860_N1.zip (658 KB)
| File | Memory | Size |
|---|---|---|
0281011627_9651128880_SW1037369860_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011627_9651128880_SW1037369860_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011627_9651128880_SW1037369860_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011627_9651128880_SW1037369860_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011627_9651128880_SW1037369860_N2.zip (673 KB)
| File | Memory | Size |
|---|---|---|
0281011627_9651128880_SW1037369860_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011627_9651128880_SW1037369860_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011627_9651128880_SW1037369860_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011627_9651128880_SW1037369860_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281011627_9651128880_SW1037369860_N3.zip (673 KB)
| File | Memory | Size |
|---|---|---|
0281011627_9651128880_SW1037369860_N3_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011627_9651128880_SW1037369860_N3_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011627_9651128880_SW1037369860_N3_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011627_9651128880_SW1037369860_N3_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 5 bytes differ in the flash (2 areas: 0x007FC4–0x007FC5, 0x007FC9–0x007FCB); 362 bytes differ in the EEPROM (88 areas: 0x000002–0x000003, 0x00001E–0x00001F, 0x000023–0x000025, …).
Read #3 compared with read #1: 12 bytes differ in the flash (4 areas: 0x007FC3–0x007FC7, 0x007FC9–0x007FCB, 0x03FA86–0x03FA87, …); 376 bytes differ in the EEPROM (89 areas: 0x000001–0x000003, 0x00000B, 0x00000E, …).
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011627 1037369860 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011627 – printed 0 281 011 627 on the label |
| PSA part number | 9651128880 – printed 96 511 288 80 |
| Software (SW) | 1037369860 – also written SW1037369860 |
| Upgrade / SW upg. | none – your tool shows 1037369860 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 2 MB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC16C34 (fichier d’origine in French, file ori in Italian).
Notes on this file
We read three EDC16C34 ECUs running software 1037369860 for this page. Hardware 0281011627 is known with 2 software versions in our catalogue; this page is 1037369860. Engine: Peugeot 307 1.6 HDi (110 hp).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C34 housing shows the hardware number 0 281 011 627 and the PSA number 96 511 288 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037369860 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037369860 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037369860 again |
Your tool should show 1037369860 as SW and either nothing or 1037369860 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281011627: SW 1037371081 (PSA 9656161880) – 307 1.6 HDi
- Other Peugeot 307 EDC16C34 files: 0281011629 · 1037371536 · 0281011863 · 1037371540 · 0281011863 · 1037371540 upg. 1037380727 · 0281011629 · 1037374179 · 0281011863 · 1037375526
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011627 1037369860 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 307 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037369860.
My tool shows SW 1037369860 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 627 and 96 511 288 80 on the label; if the upgrade line is empty or repeats 1037369860, this is your file.
Same hardware 0281011627 but my tool shows SW 1037371081?
Then you need the other file for this hardware: SW 1037371081 with PSA 9656161880, sold on its own page. 0281011627 alone is not enough to choose.
Why are there 3 downloads for one software?
We read 3 ECUs running 1037369860. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor 307?
Yes, as read. This is the original state of ECU 0281011627, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
