EDC15C2 0281010591 1037353871 1037367939 – original full BDM backup from a Bosch EDC15C2 fitted to the Citroën Jumpy 2.0 HDi (PSA 9651073180): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 409 KB)
✔ EDC15C2 0281010591 1037353871 1037367939 full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (409 KB) with the complete memory of a Bosch EDC15C2, read on the bench (Citroën Jumpy 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Fiat Scudo | 2.0 JTD | twin model – same vehicle as the Citroën Jumpy, Fiat badge |
| Peugeot Expert | 2.0 HDi | twin model – same vehicle as the Citroën Jumpy, Peugeot badge |
| Citroën Jumpy | 2.0 HDi | confirmed for this software |
Do not rely on the model alone: check HW 0281010591 and PSA 9651073180 on the label, then 1037353871 and 1037367939 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010591_9651073180_SW1037353871_MJ1037367939_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010591_9651073180_SW1037353871_MJ1037367939_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
EDC15C2 0281010591 1037353871 1037367939 – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010591 – printed 0 281 010 591 on the label |
| PSA part number | 9651073180 – printed 96 510 731 80 |
| Software (SW) | 1037353871 – also written SW1037353871 |
| Upgrade / SW upg. | 1037367939 – also written MJ1037367939; your tool shows SW 1037353871 and SW upg. 1037367939 |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 409 KB, instant download after payment |
Notes on this file
The factory read 1037353871 (before the update) is sold on its own page.
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C2. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC15C2 housing shows the hardware number 0 281 010 591 and the PSA number 96 510 731 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037353871 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037353871 |
| SW upg. (SW màj., soft up, UpgSW) | 1037367939 |
Two numbers = this file: SW 1037353871 and SW upg. 1037367939. One number 1037367939 alone = still this file. 1037353871 twice = the factory read, sold on its own page.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037367939 | SW 1037353871 / SW upg. 1037367939 | Jumpy 2.0 HDi | this file |
| base (no upgrade) | SW 1037353871 | Jumpy 2.0 HDi | open |
- Other Citroën Jumpy EDC15C2 files: 0281010359 · 1037353497 · 0281011343 · 1037364457 · 0281011343 · 1037364457 · 0281011342 · 1037364458 · 0281011247 · 1037368842
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010591 1037353871 1037367939 a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Jumpy 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037353871.
My tool shows SW 1037353871 and SW upg. 1037367939 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037367939, and 1037353871 is the base number the ECU still reports.
My tool shows only “SW upg. 1037367939” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC15C2. Confirm 0281010591 and 9651073180 on the label and you are good.
Does it fit the Fiat Scudo 2.0 JTD?
Yes – the Scudo is the twin of the Citroën Jumpy: same engine, same EDC15C2. Check 0 281 010 591 and 96 510 731 80 on the label and software 1037353871 in your tool before ordering.
Does it fit the Peugeot Expert 2.0 HDi?
Yes – the Expert is the twin of the Citroën Jumpy: same engine, same EDC15C2. Check 0 281 010 591 and 96 510 731 80 on the label and software 1037353871 in your tool before ordering.
Can I write 1037367939 on a car that still runs 1037353871 without update?
Hardware and PSA numbers are identical, so yes – but you would be applying the update yourself. To put the car back in its own state, use the base file 1037353871.
