EDC15C2 0281011342 1037376576: the unmodified full BDM backup of a Bosch EDC15C2 fitted to the Citroën Jumpy 2.0 HDi (PSA 9659440280) – external flash 512 KB + EEPROM 95080 (1 KB) read on the bench.
What you get (3 ZIPs, 1.2 MB in total)
✔ EDC15C2 0281011342 1037376576 full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC15C2, read on the bench (Citroën Jumpy 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Also, the download opens as soon as the payment is confirmed.
Three independent reads of the same software, from three different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Citroën Jumpy | 2.0 HDi | — | confirmed for this software |
| Fiat Scudo | 2.0 JTD | 94 hp / 69 kW | twin model – same vehicle as the Citroën Jumpy, Fiat badge |
| Peugeot Expert | 2.0 HDi | — | twin model – same vehicle as the Citroën Jumpy, Peugeot badge |
Two Jumpy with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011342, PSA 9659440280 – and the software 1037376576 shown by your tool before ordering.
If your Jumpy shows HW 0281011342 but SW 1037364458 (PSA 9651175080), you need this other file instead.
Archive contents
Read #1 – 0281011342_9659440280_SW1037376576_N1.zip (407 KB)
| File | Memory | Size |
|---|---|---|
0281011342_9659440280_SW1037376576_N1_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011342_9659440280_SW1037376576_N1_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011342_9659440280_SW1037376576_N2.zip (422 KB)
| File | Memory | Size |
|---|---|---|
0281011342_9659440280_SW1037376576_N2_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011342_9659440280_SW1037376576_N2_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281011342_9659440280_SW1037376576_N3.zip (422 KB)
| File | Memory | Size |
|---|---|---|
0281011342_9659440280_SW1037376576_N3_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011342_9659440280_SW1037376576_N3_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 4 bytes differ in the flash (2 areas: 0x07EC12–0x07EC13, 0x07EC3A–0x07EC3B); 186 bytes differ in the EEPROM (29 areas: 0x000000, 0x000002, 0x000005–0x00000C, …).
Read #3 compared with read #1: 4 bytes differ in the flash (2 areas: 0x07EC12–0x07EC14, 0x07EC3B); 219 bytes differ in the EEPROM (39 areas: 0x000000, 0x000002, 0x000005–0x00000C, …).
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281011342 1037376576 – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011342 – printed 0 281 011 342 on the label |
| PSA part number | 9659440280 – printed 96 594 402 80 |
| Software (SW) | 1037376576 – also written SW1037376576 |
| Upgrade / SW upg. | none – your tool shows 1037376576 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 1.2 MB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
We read three EDC15C2 ECUs running software 1037376576 for this page. Hardware 0281011342 is known with 3 software versions in our catalogue; this page is 1037376576.
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C2 you will read 0 281 011 342 (hardware) and 96 594 402 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037376576 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037376576 again |
Your tool should show 1037376576 as SW and either nothing or 1037376576 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same software 1037376576: base
- Same hardware 0281011342: SW 1037364458 (PSA 9651175080) – Jumpy 2.0 HDi · SW 1037371449 (PSA 9654693380) – Expert 2.0 HDi
- Other Citroën Jumpy EDC15C2 files: 0281010359 · 1037353497 · 0281010591 · 1037353871 · 0281010591 · 1037353871 upg. 1037367939 · 0281011343 · 1037364457 · 0281011343 · 1037364457
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011342 1037376576 a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Jumpy 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037376576.
My tool shows SW 1037376576 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 342 and 96 594 402 80 on the label; if the upgrade line is empty or repeats 1037376576, this is your file.
Does it fit the Fiat Scudo 2.0 JTD?
Yes – the Scudo is the twin of the Citroën Jumpy: same engine, same EDC15C2. Check 0 281 011 342 and 96 594 402 80 on the label and software 1037376576 in your tool before ordering.
Does it fit the Peugeot Expert 2.0 HDi?
Yes – the Expert is the twin of the Citroën Jumpy: same engine, same EDC15C2. Check 0 281 011 342 and 96 594 402 80 on the label and software 1037376576 in your tool before ordering.
Same hardware 0281011342 but my tool shows SW 1037364458?
Then you need the other file for this hardware: SW 1037364458 with PSA 9651175080, sold on its own page. 0281011342 alone is not enough to choose.
Why are there 3 downloads for one software?
We read 3 ECUs running 1037376576. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor Jumpy?
Yes, as read. This is the original state of ECU 0281011342, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
