EDC15C2 0281010816 1037353626 is the original full BDM backup of a Bosch EDC15C2 fitted to the Fiat Scudo 2.0 JTD (PSA 9644853080): external flash 512 KB + EEPROM 95080 (1 KB), read on the bench and delivered unmodified.
What you get (ZIP, 366 KB)
✔ EDC15C2 0281010816 1037353626 full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC15C2 used in the Fiat Scudo 2.0 JTD: external flash 512 KB + EEPROM 95080 (1 KB) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën Jumpy | 2.0 HDi | — | — | twin model – same vehicle as the Fiat Scudo, Citroën badge |
| Fiat Scudo | 2.0 JTD | — | — | confirmed for this software |
| Peugeot Expert | 2.0 HDi | RHZ | 110 hp / 80 kW | twin model – same vehicle as the Fiat Scudo, Peugeot badge |
Two Scudo with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010816, PSA 9644853080 – and the software 1037353626 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010816_9644853080_SW1037353626_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010816_9644853080_SW1037353626_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010816 1037353626 – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010816 – printed 0 281 010 816 on the label |
| PSA part number | 9644853080 – printed 96 448 530 80 |
| Software (SW) | 1037353626 – also written SW1037353626 |
| Upgrade / SW upg. | none – your tool shows 1037353626 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 366 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
This page covers one exact software: EDC15C2 0281010816 with SW 1037353626. Another number on your tool means another file – use the search or ask us.
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 010 816 and 96 448 530 80. The 1039S… sticker is not a software number – 1037353626 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037353626 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037353626 again |
Expected ID screen: SW 1037353626, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010816 1037353626 a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Fiat Scudo 2.0 JTD application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037353626.
My tool shows SW 1037353626 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 816 and 96 448 530 80 on the label; if the upgrade line is empty or repeats 1037353626, this is your file.
Does it fit the Citroën Jumpy 2.0 HDi?
Yes – the Jumpy is the twin of the Fiat Scudo: same engine, same EDC15C2. Check 0 281 010 816 and 96 448 530 80 on the label and software 1037353626 in your tool before ordering.
Does it fit the Peugeot Expert 2.0 HDi?
Yes – the Expert is the twin of the Fiat Scudo: same engine, same EDC15C2. Check 0 281 010 816 and 96 448 530 80 on the label and software 1037353626 in your tool before ordering.
Does the EEPROM contain the immobiliser of the donor Scudo?
Yes, as read. This is the original state of ECU 0281010816, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
